Bakers Pride CookLine XSG-36 Specification

CookLine
COUNTERTOP GAS
BAKERS
PRIDE
Model XSG-36
SPECIFICATIONS
Gas counter top griddles with a low profile design that are only 13
1/4" tall to grilling surface making them ideal for use on
refrigerated cabinets or counter tops.
XG Series Griddles are designed to mix and match with the XX
Series Char Broilers and XOB Series Open Burner counter top
ranges.
The griddle plate is 1" thick (25.4mm) and 24" deep (610mm),
polished, cold- rolled steel. Six widths are available from 24"
(610mm) to 72" (1829mm) in one foot increments.
The XG Series features high-performance, energy-efficient, 30,000
BTUH burners located every 12" with individual, operator-controlled
valves and are available in three control types: manual,
thermostatic or snap-action. Snap-action controls are supplied with
NEMA 15-P cord & plug in 120V.
The interior combustion chamber is heavy-duty heat resistant 11-
and 16-gauge steel, and is hand-welded for strength and durability.
Standard features include all stainless steel exterior, spatula-width
front grease trough, stainless steel landing ledge and large
capacity, slide-out grease pan. Additional features include
individual 3/4" NPT rear gas connection in natural or LP gas,
pressure regulator and 4" (102mm) NSF approved legs with
adjustable bullet feet. Stainless steel splash guards are
continuously welded to the griddle plates.
One year limited parts and labor warranty.
BAKERS PRIDE OVEN COMPANY, INC.
30 Pine Street, New Rochelle, NY 10801
914/576-0200 • 1-800-431-2745 • fax 914/576-0605
BAKERS
PRIDE www.bakerspride.com
S E R I E S
GRIDDLES
Job ____________
GAS COUNTER TOP GRIDDLES
Manual Thermostatic
XMG-24 XTG-24
q q
XMG-36 XTG-36
q q
XMG-48 XTG-48
q q
XMG-60 XTG-60
q q
XMG-72 XTG-72
q q
STANDARD FEATURES
1" thick griddle plate
q
24" deep grilling surface
q
Heavy gauge, hand-welded, heat-resistant steel combustion
q
chamber
30,000 BTUH burners every 12"
q
Up to 180,000 total BTUH in natural or LP gas
q
Individually operated burner valves with manual, thermostatic
q
or snap-action controls
All stainless steel exterior
q
Stainless steel landing ledge
q
Stainless steel, welded splash guards
q
Low profile, counter top design - only 13 1/4" to grilling
q
surface
Front grease trough
q
Stainless steel, slide-out grease pan
q
Heavy-duty 4" NSF approved adjustable chrome legs with
q
bullet feet
3/4" (19mm) NPT rear gas connection
q
Limited one year parts & labor warranty
q
OPTIONS & ACCESSORIES
Stainless steel front-mounted work deck with or without
q
sauce pan cut-outs
Condiment rail
q
Gas connector hoses
q
Equipment stands with or without casters
q
Grooved griddle surface in 12" increments
q
Two year limited warranty
q
CERTIFICATIONS
Continuous product improvement is a policy of Bakers Pride Oven Company.
Therefore, specifications and design are subject to change without notification
Item # ___________
G
Snap-Action
XSG-24
q
XSG-36
q
XSG-48
q
XSG-60
q
XSG-72
q
®
CERTIFIED
