Technical information
Cable light
KL1242
Material
Aluminium*
Size
Round 68 x 160mm
Weight above water
Weight under water
LED type
LED 20W - 1500 Lumen
Colour temperature
5500K - 6000K
Variable light power two steps
30% - 100%
Cable length
Pressure tested to 25 bar
Battery tank
FX1204
Material
Aluminium*
Size
65 x 75 x 230
Weight above water
1,6 kg
Weight under water
1,0 kg
Battery type
NiMH
Battery power
12 Volt 3,8 Ah
Charger
MP1100 / MP2500
Charging time
appr. 4 / 2 hours
appr. 140 min. **
Capacity met 1500Lumen LED HEAD
Quick release system
no
Pressure tested to 25 Bar
* In accordance with American Military Standard MIL-A-8625-E type 3 class 2.
Also the coating is impregnated with Teflon.
** Measured by 100% power and water temperature 20°Celsius.
Warranty
The Metalsub torch warranty will start on the date of purchase. The warranty period is 24 months and will only count
when the torch has been used in the way the manufacturer advises and has explained in the outlines.
During this warranty period we will repair all problems that are caused by manufacture related mistakes.
We will take no responsibility for damage that is done through misuse or normal wear and tear of the Metalsub dive
light for whatever reason. There is no warranty on the o-rings. The warranty period of the battery pack is 12 months
from purchase date. Until 36 months from purchase we offer a fair settlement.
We will give no warranty when any person has carried out any repair or rebuilding on our products by themselves!
All goods being returned for warranty must be returned prepaid, sufficiently packed under the owners risk to your
Metalsub dealer.
Metalsub® The Netherlands, 2010
0,5 kg
0,1 kg
100 cm.
PR1209 / FX1209
Aluminium*
65 x 75 x 480
65 x 75 x 340
2,9 kg / 2,5 kg
1,7 kg / 1,4 kg
NiMH
12 Volt 9 Ah
12 Volt 13 Ah
MP2500
appr. 7 hours
appr. 4,5 hours
appr. 480 min. **
appr. 300 min. **
/ no
dealer
Manual
PR1213
Aluminium*
3,7 kg
2,7 kg
NiMH
MP2500
CABLE LIGHT KL1242-LED1500
10
Battery tank PR1209 / PR1213
Battery tank FX1204 / FX1209
®
