SUNBOLT LED SPOTLIGHT
OPERATING INSTRUCTIONS
200-1006 Sunbolt 6 - 18°
200-1008 Sunbolt 6 Tac - 8°
200-1009 Sunbolt 6 Tac-Strobe 8°
The SUNBOLT Spotlight is a powerful
spot/search light. Key features include:
• Fully submersible to 24 ft / 7 m
• Instantly turns on to Low Light Level
• Minimal Projected Heat, and no warm
up/cool down is needed

IMPLEMENTATION

1. Unit mounts on a standard ¾" inch
diameter post.
2. Turn Diamond Knob clockwise to secure to
post.
3. Turn Diamond Knob on side of head
counter-clockwise to loosen brake, holding
the back of the unit by the handle.
4. Adjust up/down and tighten brake
clockwise.

POWER SOURCE: AC Power Supply

• Dimensions: 12" x 8" x 5" (305 x 203 x 127
mm)
• 100 – 240 VAC 50/60 Hz Power Supply
• 220 Watt Power Consumption
• Power Switch
• On LED Indicator
• Dimming Knob
• Insert keyed connector on Power Supply,
and secure by turning ring cap clockwise
(below)

OPERATIONAL MODES

The SUNBOLT Spotlight can cycle through -3-
Operational Modes, by pushing the black rubber
button switch at the center-top of the Power
Source.
All Sunbolt Models will automatically turn on in
Low Mode. Modes are as follows:
Mode Light Output
Low
Medium
High
Please see the two DMX connectors for external
control.
P/N 200-1009 ONLY:
Pressing one more time (after High Mode) will
activate the FoxFury Turbo Strobe mode.
NOTE: This mode may induce vertigo. Prolonged
exposure has shown to cause vomiting as well.
Foxfury SUNBOLT Inst Manual 12 11
3,000 Lumen
7,000 Lumen
11,000 Lumen
