Carbon X220

User Manual

Table of Contents

Need help?

Do you have a question about the Carbon X220 and is the answer not in the manual?

Questions and answers

Summary of Contents for X2 Computing Carbon X220

Page 1 Carbon X220 User Manual 1 ...
Page 2: Table Of Contents
Table of contents First Steps…………………………………......3 Introduction……………………………………………..….. 4 Getting to know your tablet……………………..5 View and interface…………………………………………..5 Packing List …………………………………………..13 Optional Accessories……………………………….… 14 Getting Started………………………………………….… 16 Connecting the AC Power………………………..… .. 16 Turning the tablet on and off…………………… ... 17 The optimised use for sunlight readable touch screen………………………………………...18 Specifications…………………………………………….…...
Page 3: First Steps
First Steps This manual will help you get the most from your tablet. Please read it carefully before starting Let your tablet acclimatise itself Do not power up your tablet immediately if it has been exposed to hot or cold conditions. Instead, allow it to adjust gradually to room temperature over a three to four hour period.
Page 4: Introduction
Introduction Your tablet features the latest advances in portable computing technology with a modular design that provides maximum expandability without compromising portability. WARNING - Never try to disassemble or back engineer your tablet as we will not be responsible for any damage caused if you do so and this action would void your warranty Please note that some of the features mentioned in this manual might not be included on your tablet or may vary slightly. ...
Page 5: Getting To Know Your Tablet
Power adaptor and cord (12v --- 4.16A) LAN adaptor cable Getting to know your tablet Front View with Capacitive touch panel 5 ...
Page 6 Front View with Resistive touch panel 6 ...
Page 7 1. LCD Panel This tablet is equipped with a 10.1” LCD display with a resolution of up to 1280 x 800 2. Speaker Two Piezoelectric speaker 3. Front Camera 200MP, USB interface 4. Reset Function Hall IC switch on handle(EC Control) – External magnet action ...
Page 8 Right Side View 5. Wi-Fi Indicator & Power LED 5.1 WIFI Indicator Lights up Green when the Wi-Fi device is turned on. Light will flicking when data transferring No light when Wi-Fi stops operation 5.2 Power Indicator Blue: Connect to DC Power No Light: No DC Power Flash: System standby 6.
Page 9 7. Battery Indicator Status Amber GREEN Flash 0%-40% Charge(S0,S3,S5) Flash 41%-80% 81%-100% OFF Flash 0%-40% No Charge (S0) 41%-80% 81%-100% OFF 0%-40% No Charge (S3,S5) 41%-80% 81%-100% OFF Note: Battery charge current had 3 level can be selected. Low voltage charge: 0.368A; Normal Charge: 2A; Fast charge: 4A.
Page 10 Rear View with 8000mAh battery 10 ...
Page 11 Rear View with 16000mAh battery 8. Lock hole For Kingston locker 11 ...
Page 12 9. Rear Camera Rear facing 5Mega Pixel with auto flash and LED flash 10. VESA Mounting 11. WIFI Logo IEEE 802.11b/g/n/ Wireless card with WIFI Antenna 12. Kick stand Integrated rear friction grip kickstand for use in both landscape & portrait orientation, with Indexing for portrait. ...
Page 13 13. SIM Card Slot (not supported with Carbon X220 device) Slot for fitting a SIM Card 14. Micro-SD Slot Slot for fitting a Micro-SD card 15. DC Jack DC jack port for charging the tablet (12V --- 4A). 16. Pogo connector (not supported with Carbon X220 device)
Page 14 Packaging list This product is shipped with the items list below. Please make sure that all are in Gift box. 1 piece of Rugged Tablet PC user manual 1 CD for Recovery CD for Operation System (Windows embedded standard 7) 1 piece of 12V Adapter w/ Standard Power Cord 1 piece of Mini HDMI to RJ45 (female) Adapter cable 1 piece of Mini USB to standard USB(female) adapter cable...
Page 15: Optional Accessories
Optional accessories Hand strap 15 ...
Page 16: Getting Started
Getting Started This chapter guides you to get the X2 Carbon ready for operating. Connecting the AC Power Our tablet PC can operate either on the external AC power adapter or internal battery power. It is suggested that you use AC power when you start up the tablet PC first time. Use only the AC adapter included with your tablet PC.
Page 17: Turning The Tablet On And Off
3. When the AC adapter is connected, the Battery Pack is also charging. You can check the Battery Status LED indicator to see the current progress. The indicator turns to green when it is fully charged. When you disconnect the AC adaptor, disconnect from the electrical outlet first Caution - and then from the tablet PC.
Page 18: Touch Screen
1. To turn off the tablet PC power, use the ‘Shut Down’ command on your operating system. Caution - If you have to turn the tablet PC on again immediately after turning it off, wait for at least five seconds. Turning the tablet PC off and on rapidly can damage it. The optmised Use for Sunlight Readable Touch Screen With the imposed reflective function, the modified LCD can reflect the ambient light passing the LCD cell and utilize the reflected light beams as its illumination.
Page 19 Caution - Although transflective LCD is mainly used in outdoor environment and it may increase the reflective lights under sunlight, it is suggested that you should keep the LCD in an appropriate temperature for operation and storage, and avoid direct sunlight if possible.
Page 20: Specifications
Specification Component Description 325.0mm(L)x197.3mm(W)x27.8mm(D) Dimension Intel Cedarview-M N2600 Dual-core 1.6GHz Processor Intel NM10(Tiger point ) Chipset 10.1” Toughened Screen (LVDS), 1280 x 800 WXGA 16:10 Aspect Ratio, 350CD/m2, IPS LCD panel 10 Multi Capacitive touch panel and single Resistive touch panel, Surface Hardness 7H and IK08 compliant, Touch panel 2G DDR3 (expansion 4G DDR3) –...
Page 21 Component Description Microsoft Windows 7 Operating System FCC / CE / RCM Regulations RGB LED, UART interface, 5V operation voltage Halo LED 200MP, USB interface Front camera 500MP+AF+ LED flash Rear camera three kinds of optional I/O cover (with Logo, with button hole, without Logo and button hole) I/O cover Hand strap for rotating and handle Hand strap...
Page 22 part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
