Instruction Manual
KB-1000/JS
JOYSTICK CONTROLLER
Please read this manual thoroughly before use and keep it handy for future reference.
Version 2.0 07/2010

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KB-1000/JS and is the answer not in the manual?

Questions and answers

Summary of Contents for Genie CCTV KB-1000/JS

  • Page 1 Instruction Manual KB-1000/JS JOYSTICK CONTROLLER Please read this manual thoroughly before use and keep it handy for future reference. Version 2.0 07/2010...
  • Page 2 WARNING AND CAUTION WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTILATION GRILLS OR OTHER OPENINGS ON THE EQUIPMENT. CAUTION EXPLANATION OF GRAPHICAL SYMBOLS The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3 FCC COMPLIANCE STATEMENT FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL ENVIRONMENT.
  • Page 4 IMPORTANT SAFEGUARDS 1. Read these instructions. 2. Keep these instructions in a safe place for future reference. 3. Heed all cautions and warnings. 4. Follow all instructions. 5. Do not use this apparatus near water. 6. Clean only with a dry cloth. 7.
  • Page 5: Table Of Contents

    Table of Contents Chapter 1.0 INTRODUCTION 1.1 Features 1.2 Unpacking Chapter 2.0 INSTALLATION 2.1 Connection Diagram 2.2 Dip Switch Setting 2.3 Basic Operation 2.4 Configuring the Controller 2.5 Operating the Controller Chapter 3.0 KEY Description 3.3.1 Key Description of the Controller 3.3.2 Keys for DVR Appendix A SPECIFICATION...
  • Page 6: Features

    Chapter 1 INTRODUCITON 1.1 Features This joystick controller is designed to control 64 dome cameras. It is expandable to 255 dome cameras in simplex control mode. Roll over key functions make it capable of controlling a variety of external switching devices such as Multiplexers and/or Digital Video Recorders. The joystick controller features: •...
  • Page 7: Unpacking

    1.2 Unpacking Unpack the equipment and make sure all listed items are included in the box. Contents of Joystick Controller box Joystick C ontroller ------------------------------- 1 Junction Box --------------------------------------- optional 3m Cable -------------------------------------------- optional M4 Self Tapping Screws ------------------------- optional Instruction Manual --------------------------------- 1 12VDC SMPS -------------------------------------- 1...
  • Page 8: Chapter 2.0 Installation

    Chapter 2 INSTALLATION 2.1 Connection Diagram 2.1.1 Basic Installation Diagram POWER AC 24V STP AWG # 22 4 ALARM INPUT VIDEO 1 AUX OUTPUT 4 ALARM INPUT 1 AUX OUTPUT POWER AC 24V TXB TXA RXB RXA FGND AC- AC+ BNC MONITOR RS-422 RS-485 or...
  • Page 9 2.1.2 Single DVR Configuration POWER POWER POWER AC 24V AC 24V AC 24V AWG # 24 VIDEO 4 ALARM INPUT 4 ALARM INPUT 1 AUX OUTPUT 1 AUX OUTPUT J4 ALARM2 ALARM1 COM B COM A NC B NC A NO B NO A ALARM8...
  • Page 10 2.1.3 Single User with Two DVR Configuration POWER POWER POWER AC 24V AC 24V AC 24V AWG # 24 VIDEO 4 ALARM INPUT 4 ALARM INPUT 1 AUX OUTPUT 1 AUX OUTPUT Camera 1~16 Camera 17~12( 15) 1ST MAIN MONITOR SPOT MONITOR 2ND MAIN MONITOR TXB TXA RXB RXA...
  • Page 11 2.1.4 Two DVR with Slave Controller POWER POWER POWER AC 24V AC 24V AC 24V AWG # 24 VIDEO 4 ALARM INPUT 4 ALARM INPUT 1 AUX OUTPUT 1 AUX OUTPUT Camera 1~16 Camera 17~12( 15) 1ST MAIN MONITOR SPOT MONITOR 2ND MAIN MONITOR TXB TXA RXB RXA FGND AC- AC+...
  • Page 12: Dip Switch Setting

    2.2 Termination & Dip Switch Settings The first and last devices in an installation (dome and keyboard controller) must have the data line terminated by setting the DIP switch. Without proper termination, there is potential for control signal errors. Total cable length for communication should not exceed 1.2Km Refer to Figure 7 for setting the dome camera and keyboard controller termination.
  • Page 13: Basic Operation

    Figure 7 - Rear View of the Keyboard. Figure 7 – Termination and ID Switches. 2.3 Basic Operation The joystick controller shows the following screens in selected modes and menus. When the keyboard controller is powered on, a password is needed to access the keyboard controls. CONTROLLER SYS V x.x Password :_ Unless the password has been changed, 9999+Enter is the default administrator’s password...
  • Page 14: Configuring The Controller

    When you need to control the DVR, press key. The LCD screen shows the following DVR modes. LCD Display in DVR Mode 1 Cam : 0001E PM 09 : 34 : 04 … DVR - 0001 SEQ SEARCH SEL REPLAY ACK SPOT LCD Display in DVR Mode 2 Cam : 0001E Press...
  • Page 15 CONFIGURATION (Shft + Menu CONFIGURATION) CONFIGURATION Key Beep : ON / OFF Log_Out : NO /1Min ~30Min User Password Admin Password Save and Exit - Key Beep : ON - Enable key beep sound, OFF - Disable beep sound. - Log_Out : OFF~ 30Min - After elapsed setup time, keyboard locks automatically.
  • Page 16 Cam2 (Shft + Menu PORT SETUP MENU Cam2) CAM2 PORT SETUP MENU Device : Camera / None Baud Rate : 9600 / 2400~230K Save and Exit Device : Select Device to be controlled ( Camera / None ) Baud Rate : Communication speed (2400/ 4800/ 9600/19200/ 38400/ 57600/ 11.5K /230K) Save and Exit Press key to exit without saving the data.
  • Page 17 Device : Select Device to be controlled ( DVR / Alarm / AUX IN / AUX IO /None ) Baud Rate : Communication speed (2400/ 4800/ 9600/19200/ 38400/ 57600/ 11.5K /230K) Save and Exit Press key to exit without saving the data. Camera (Shft + Menu Camera)
  • Page 18 Alarm Beep -- Enable or disable the beep sound when an alarm is activated. Alarm Dwell – The time the alarm is extended to, until returning to programmed time. Alarm Schedule (Shft + Menu Alarm Alarm Action) ALARM SCHEDULE page : 001 DOME : ID of the dome to be programmed.
  • Page 19 Night Shot Setup (Shft + Menu Schedule Night Shot) Night Shot Setup Night shot option is enabled/disable (ON) by Night Shot : OFF / ON On time and Off time can be setup using On Time : 00 00 Off Time : 00 00 Save and Exit Night shot enable option changes low light sensitivity by removing the IR cut filter from the camera lens.
  • Page 20: Operating The Controller

    2.5 Operating the Controller 2.5.1 Selection of the dome camera ( ID of the Dome Camera) There are three ways of dome camera selection (Next) or (Prev) . With these selections, the keyboard controller has full control of the selected dome camera. 2.5.1 Selection of the DVR (ID of the DVR) DVR must be selected before being controlled by the joystick controller.
  • Page 21 (1) The first time that Function Key is pressed a Search menu is displayed, as below. * Note: External Search menu is used for Mpeg DVR. (2) Second page (3) 3 page...
  • Page 22 2.5.3 Joystick (1) Menu Control (2) Pan/Tilt/Zoom Control 2) Press [SYS] button to use “Preset or Tour”...
  • Page 23 a. Preset: Press “SYS” button first, then select Preset <ex> Preset No3: Move the camera to your desired area and then press “No3-> Shift-> Preset”. PRESET SHIFT b. Go to : To move preset position, press Number then Preset. <ex> Preset No3 : Press “No3” then press “Preset” button...
  • Page 24: Key Description Of The Controller

    Chapter 3 KEY Descriptions 3.3.1 Key descriptions for the Controller Function Key Buttons Descriptions Camera ID selection with Cam key. Numeric Function number selection with function keys. (e.g., 1+Cam, 3+Tour, 5+Scan, 6+Prst) Displays the selected camera on the spot out of the multiplexer and allows the camera to be controlled by the keyboard controller, if the selected camera is a dome Camera camera.
  • Page 25: Keys For Dvr

    Overrides auto focus. Return to Auto Focus mode by manu. Manual Focus Overrides auto iris. Moving the joystick reactivates Auto Iris mode. Manual Iris Set of functions will be displayed each key pressed. Function Scroll º/sec. Once pressed turbo key, manual control speed goes up to 360 Turbo Speed To go back to normal speed, press the key once more.
  • Page 26: Appendix A Specification

    Appendix A SPECIFICATION Power Consumption 12VDC, 0.5A Control Method RS-485, RS-232C Baud Rates 2400~230K bps Operating Temperature 0°C to 50°C (32 F to 140 Humidity 0 to 90%RH (non-condensing) Storage temperature -20°C to 60°C (-40 F to 122 Dimension Professional Joystick : 390x190x65 Weight Professional Joystick : 1.2kg Dome Connection : Max 64 (simplex 256)
