INST LL TION INSTRUCTIONS
SPECIFIC TIONS
• Standard solenoid: 24 V C
• Pressure range: 6-200 psi
• Voltage: 24 V C, 60 Cycle, .43 mps Inrush, .25 mps Holding
BEFORE INST LL TION
1.Flush system thoroughly before installing valves.
2.Make sure you have sufficient water supply, pressure & flow.
INST LLING V LVE WITH
D PTERS
1.Wrap adapters with 2 or 3 complete wraps of Teflon tape around threads.
2.Hand tighten adapters into valve.
3.Carefully tighten the adapters one additional turn past hand tight.
4.Do not use flow control handle as a lever.
C UTION: DO NOT OVER-TIGHTEN
D PTERS!
OPER TING V LVE M NU LLY
1.Turn solenoid on/off handle 180 degrees counter-clockwise to open valve.
2.Turn solenoid on/off handle 180 degrees clockwise to close valve.
3.Solenoid on/off handle must be fully closed for proper valve operation.
K-R IN M NUF CTURING CORP.
1640 ustralian venue
Riviera Beach, FL 33404 US
PH: 1-561-844-1002 / 1-800-735-7246
F X: 1-561-842-9493
www.krain.com
Pro Series
MODEL
#7202
© K-R IN Manufacturing Corp.
Part Number: 30006101
Rev 13
MODEL
#7215
ELECTRIC
V LVES
MODEL
#7201
MODEL
#7201-J
