SPECIFICATIONS
2,500 lbs
33.00"
76.50"
48.00"
33.00"
33.00"
8.00"
19.70" x 32.50"
515 lbs
Page 1
Model 3182
2,500 Lbs Power Train Table/Lift
OWNER'S MANUAL
Advertisement
Summary of Contents for AFF 3182
- Page 1 Model 3182 2,500 Lbs Power Train Table/Lift OWNER'S MANUAL CONTENTS: Page 1 Specifications Page 2 -3 Warning Information Page 3 Setup Page 4 Operating Instructions Page 5 Preventative Maintenance Page 5 Troubleshooting Page 6 Diagram Page 7 Replacement Parts SPECIFICATIONS...
- Page 2 WARNING: Read all instructions and safety warnings before operating this equipment. Failure to follow the instructions and safety warnings may result in personal injury or property damage. WARNING The use of portable automotive lifting devices is subject to certain hazards that cannot be prevented by mechanical means, but only by the use of care and common sense.
- Page 3 WARNING (continued) • Adequately support the vehicle before starting repairs. Consult the in ground or above ground lift manufacturer for the recommended support procedure and under hoist support stand locating points. • Support the engine with a stand before unbolting the transmission from the engine. •...
- Page 4 WARNING: Ensure that you read and understand all safety instructions and warnings before use. OPERATING INSTRUCTIONS IMPORTANT: Become familiar with the pedal operation of the air/hydraulic foot pump before using the lift table under load. Stepping on the PUMP end of the foot pump pedal will engage the pump and raises the lift table under load.
- Page 5 ● Safety latches are in use ● Lower safety latches ● Poor performance ● Air trapped in system ● Allow pressurized reservoir air to escape ● Unit still does not operate ● Contact an AFF authorized repair depot Page 5...
- Page 6 Page 6...
- Page 7 PARTS LIST Description Description Base Assembly Axle Caster Lock Nut Caster with locker Hand Wheel Washer Screw A Washer Bolt Snap Ring Plate Axle Anti-wear Block Bolt Bush Bolt Shaft Washer Screw B Lock Nut Saddle Bolt Wing Nut Washer Washer Lock Nut Square Wooden bar...
