IP7-SS20

Getting Started Guide

Introduction

The IP7-SS20 IP paging endpoint enables 1-way IP audio to analog

speakers from TalkMaster™ software and/or VoIP Systems supporting

industry standard SIP 2.0 (VoIP) protocols. The internal amplifier can deliver

20 watts of audio power to one or more speakers. Power must be supplied

by external 24-32V AC or DC power supply.

The SS20 is configured using TalkMaster Admin Console. This Getting

Started booklet covers basic hardware installation and software configuration

of the IP7-SS20.

Please refer to the IP7-SS20 Reference Manual available on the Software

Installation CD for additional information on installation and setup

Important Installation Guidelines

• Choose 12-18 AWG wire for speaker connections. Select wire gauge

suited to minimize power loss for specific distribution method and wire run

distances

• Do not install near power distribution equipment or noise generating

equipment such as stepper motors

• Conform to industry standard practices for grounding

• Avoid sharing AC power and audio signals in conduit runs

Page 1 of 4

IP7-SS20 Installation

Need help?

Do you have a question about the IP7-SS20 and is the answer not in the manual?

Page 1 IP7-SS20 Installation Please refer to the IP7-SS20 Reference Manual available on the Software Installation CD for additional information on installation and setup Important Installation Guidelines IP7-SS20 • Choose 12-18 AWG wire for speaker connections. Select wire gauge suited to minimize power loss for specific distribution method and wire run...
Page 2 DIN Rail until the IP7-SS20 DIN clip catches the top of the rail. Press in at the bottom of the IP7-SS20 to • Do not mix speakers tapped for 25V with a 70V distribution line or snap into place.
Page 3 Intercom’s previously recorded ID#) TalkMaster™ Server Software is a suite of Windows® based application used to configure and manage Digital Acoustics IP7™ and ii3™ Intercoms and Paging endpoints. Applications included with the TalkMaster Server are the Admin Console for configuration of the Server and IP Endpoints and the •...
Page 4 Paging Groups tab of the Operator Console Getting Started Guide Refer to the IP7-SS20 Hardware Reference Manual for detailed information on wiring, setup, configuring IP addresses and additional software settings. • The PC’s microphone is used to send audio to an IP Endpoint •...
