iStarUSA BPX-525-SA User Manual

BPX-525-SA 5.25" to 3.5" SATA 6 Gbps HDD Hot-Swap Rack with LCD
i StarUSA - Powered by iStarUSA Group
727 Phillips Drive City of Industry, CA 91748
Order Information:
Model Number: Color:
BPX-525-SA
Black

Introduction:

The iStarUSA BPX-525-SA simpli es your storage needs. The trayless design
allows you to hot-swap a HDD easily without the hassle of dealing with screws
or cables. The stylish LCD powers on automatically when an HDD is inserted; it
displays the HDD's temperature and fan speed. Heat dissipation is enhanced
by a 40mm fan with three speed modes. The metal key lock secures your hard
drive to prevent unauthorized access.

Features:

• Easy installation
• Supports 3.5" SAS I/II, SATA I/II/III hard drives
• Data transfer rate up to 6.0 Gbps
• Metal key lock
• LED indicators for power & HDD activity
• LCD to display temperature and fan speed
• Failure alarm warning system equipped
United States of America
Tel: 1-626-303-8885
Toll-Free: 1-888-989-1189
Email: sales@istarusa.com
UPC Code:
846813036177

Specifications:

Hot Swap
Standard Drive Bays
Dimensions (W x H x D)
Material
HDD Interface
Weight
Cable

Hardware Information: Front View

D3
D1
LCD: Display HDD temperature, fan speed, HDD access status,
failure warning.
Fan failure: The LCD will display fan speed as 0 rpm.
High temperature warning: When the HDD reach 55 °C / 131
°F, the temperature display will blink, and fan speed will
increase to 4500rpm.
D2
Fan speed control buttons: use + or - button to adjust fan
speed up or down.
L = low speed, 2300rpm; M = medium speed, 3600rpm;
H = high speed, 4500rpm.
D3
Key lock: The key lock secures the hard drive to prevent
unauthorized access
BPX-525-SA

User Manual

3.5" Drive: 1
5.25" Drive: 1
148mm x 42mm x 188mm
Metal body with plastic door
SATA/SAS
0.9 kg
SATA cable included (1x)
D1
D2
