Summary of Contents for Leader LM41PF
- Page 1 Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa Instruction Manual Petrol Lawn Mower LM41PF Quality controlled by Manufacturer Made in P.R.C.
-
Page 2: Table Of Contents
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa CONTENT 1. Introduction……………………………………………….3 2. Lawn Mower Assembling……………………………….4 3. Oil Level Inspection……………………………………...6 4. Fuel Tank Filling………………………………………….8 5. Cutting Instructions…………………………………..…9 6. Operation…………………………………………………10 7. Technical Data…………………………………………..12 8. Specified Conditions Of Use………………………….13 9. Emergency Procedure…………………………………14 10. Symbols…………………………………………………15 11. Safety Instructions…………………………………….15 12. -
Page 3: Introduction
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 1. Introduction 1, Brake Level 2, Upper Handle 3, Knob Lock 4, Lower Handle 5, Engine, SG350 6, Air Filter 7, Left Wheel 8, Deck 9, Right Wheel 10, Grass Bag... -
Page 4: Lawn Mower Assembling
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 2. Lawn Mower Assembling 2.1, Lower Handle Assembly 2.2, Lower Handle and Upper Handle Assembly 2.3, Brake Cable and Brake Level Assembly... - Page 5 Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 2.4, Wheel Assembly, 3 positions cutting height 34mm 54mm 68mm Left Wheel Right Wheel 2.4.1, Left Wheel Assembly, wheel equipped with bearing 2.4.2, Right Wheel Assembly, wheel equipped with bearing...
-
Page 6: Oil Level Inspection
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 3. Oil Level Inspection Engine shipped without adding oil. The engine must be filled with engine oil before being put into operation for the first time. Check the oil level whenever the appliance is to be put into operation. - Page 7 Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa To ensure quality, every piece of equipment is subject to a test operation and filled with motor oil. Oil is drained before transport; however, there can be some motor oil remains on the dip stick. Please check carefully the oil level and add motor oil again.
-
Page 8: Fuel Tank Filling
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 4. Fuel Tank Filling... -
Page 9: Cutting Instructions
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 5. Cutting Instructions... -
Page 10: Operation
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 6. Operation... - Page 11 Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa Notice: If the motor doesn’t start, please follow these steps as below,...
-
Page 12: Technical Data
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 7. Technical Data Petrol Lawnmower No………………………………………..LM41PF Engine Model………………………………………………….SG350 EC type-approval No……………….e11*97/68SA*2010/26*2728*00 Engine Displacement…………………………………………99cm Rated Power, OHV 4-stroke motor………………………….1.9kW Max. Engine Speed………………………………………..…3000rpm Fuel Tank Capacity……………………………………………0,8l Super / Unleaded petrol / E10 Oil Capacity…………………………………………………….0,35l Cutting Width…………………………………………….……..406mm Cutting Height……………………………..34-68mm with 3 positions... -
Page 13: Specified Conditions Of Use
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa The vibration emission level may be used to compare one tool with another. It may be used for a preliminary assessment of exposure. An accurate estimate of the vibratory load should also take into account the times when the tool is shut down or when it is running but not actually in use. -
Page 14: Emergency Procedure
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa The operating staff must carefully read the Operating Instructions before using the appliance. Qualification: Apart from the detailed instructions by a professional, no special qualification is necessary for appliance using. Minimum age: Persons over 16 years of age can only work on the appliance. An exception includes youngsters trained in order to reach knowledge under supervision of the trained during occupational education. -
Page 15: Symbols
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa 10. Symbols Keep a sufficient distance Caution! from the cutting knife when operating the appliance. Use the appliance only Read the Operating outside, never use it in Instruction! confined and bad ventilated areas. Risk of poisoning! Caution, risk of drawing-in! Keep distance of persons! Warning against thrown-off... - Page 16 Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa using the appliance. Minimum safe distance is 5 meter. Wear personal protective equipment. Wear solid shoes and long trousers. Never use the appliance when barefooted or in light sandals. Wear protective gloves if necessary. Use the appliance in broad daylight or in a well-lit environment.
-
Page 17: Maintenance
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa Do not incline the appliance when being started. Do not start the appliance when you are standing in front of the ejection opening. Walk! Never run! Make sure your posture is safe, especially on slopes. Do not cut on too steep slopes. -
Page 18: Inspection And Maintenance Plan
Original Safety Instruction/ Oryginalna Instrukcja Bezpieczeństwa possible, grind the knife regularly approximately after every 25 hours of operation. Make sure the knife is always counterbalanced well. For this purpose, insert a small iron axis (of 2-3mm diameter) into the central opening of the knife. -
Page 20: Ec Declaration Of Conformity
We declaring that the machinery Product name: Lawnmower, powered by Gasoline Commercial name: Lawnmower, powered by Gasoline Function: mowing Model: LM41PF Type: gasoline powered fulfils all the relevant provisions of Directives 2006/42/EC, 2004/108/EC and tested in accordance with below standards EN 836:1997+A4:2011;...
