Seppi MIDIPIERRE Operating And Maintenance Manual page 14

b. WITH ADAM™ alignment system
=
=
If they do not work in the
described positions, the PTO
shaft and all the transmission
components wear prematurely.
The product warranty becomes
null and void.
Read the PTO shaft
manual!
4.2.4 Connection of hydraulic quick couplings
for auxiliary functions
1) Connect a pair of hydraulic pipes marked with
the same colour to the tractor inlets by means of
quick couplings.
same colour
2) Check movements of the hydraulic functions and
if necessary adjust at the following flow rates:
Function
≠
MIDIPIERRE
MIDIPIERRE dt
MIDISOIL dt
MULTIFORST
STARSOIL
SUPERSOIL
MAXISOIL
4.2.5 Connection of electrical sockets
On some models, the cooling system of the
transmission is electric.
Position the control panel in the cab and fix it
properly.
Connect the three-pole electrical power connec-
tor to the tractor's socket.
Hydraulic Compacting
hood roller or
grader blade
6-10 l/min /
6-10 l/min 6 -10 /min
2 -3 l/min
6-10 l/min 6-10 l/min
10-14 l/min 25 -35 l/min
10-14 l/min 25 -35 l/min
10-14 l/min 25 -35 l/min
10-14 l/min 70 -95 l/min
If the tractor does not have a suitable socket,
connect the wires to another electricity source
according to the following indications.
Voltage
Fuse
14
not connected
12V
16A
