Acuity Controls Sensor Switch Programming Instructions

PROGRAMMING INSTRUCTIONS
Please read all 3 steps before programming
1. Enter a programming function by pressing button the number
of times as the desired function number from the tables below
(e.g., press twice for function 2, occupancy time delay).
2. LED will flash back the selected function's current setting
(e.g., 5 flashes for 10 minute time delay). To change setting,
proceed to step 3 before flash back sequence repeats 3 times.
To exit the current function or to change to a different function,
wait for sequence to repeat 3 times then return to step 1.
3. Press button the number of times indicated in the particular
function's detailed table for the NEW desired setting (e.g.,
press 3 times for 5 min). As confirmation of setting change,
LED flashes back the NEW setting 3 times before exiting.
PROGRAMMING STD.
FUNCTIONS UNIT
2
Occupancy Time Delay •
3 Dim to Off Time Delay
4 Test Mode & 100 hr Burn-In •
4 Auto Set-Point
5 Ten's Digit of Set-Point
6 One's Digit of Set-Point
7
Sunlight Discount Factor
8 Incremental Set-Point Adjust.
10 Minimum On Time •
11 Photocell Mode
12 Dual Tech. (Microphonics ) •
TM 1
14 Lamp Information •
15 Dimming Range (High Trim)
16 Dimming Range (Low Trim)
DETAILED FUNCTION TABLES
2 = Occupancy Time Delay
1 30 sec
2 2.5 min
3 5.0 min
3 = Dim to Off Time Delay
1 30 sec
2 2.5 min** 5
3 5.0 min
4 = Test Mode / 100hr Burn-In / Auto Set-Point
1
Normal*
2 Run 100 hr Burn-In
3 Run 100 hr then Auto-Setpoint
OPTIONS
P ADC D
2
The LED will blink back the ten's digit, then pause, then blink back
the one's digit. For a "0" the LED will blink very rapidly. The sequence
• • •
is repeated 3 times.
• •
3
Test Mode will disable Minimum On Time, set Occupancy Time Delay
• • •
to 30 sec, and shorten all photocell transitions and dimming rates.
• •
Mode will expire after 10 min or if function 4 is set back to Normal.
• •
5 = Ten's Digit of Set-Point
• •
1
10 fc
• •
2 20 fc
• •
3 30 fc
• • •
6 = One's Digit of Set-Point
• •
1 1 fc
• • •
2 2 fc
• •
3 3 fc
• •
• •
7 = Sunlight Discount Factor
1 x/1***
2 x/2
3 x/3
1
PDT SENSORS ONLY
4 7.5 min** 7 15.0 min
5 10.0 min* 8 17.5 min
6 12.5 min 9 20.0 min
4 7.5 min 7 15.0 min 10 0 sec
8 11 Infinite
10.0 min 17.5 min
6 12.5 min 9 20.0 min
4 Run Auto Set-Point
5 Blink back Set-Point 2
6 Test Mode 3
4 7
40 fc 200 fc
5 50 fc 8 Disable
6 100 fc 10 0 fc*
4 4 fc 7 7 fc 10 0 fc
5 5 fc* 8 8 fc
6 6 fc 9 9 fc
4 x/4* 7 x/7 10 x/10
5 x/5 8 x/8
6 x/6 9 x/9
8 = Incremental Set-Point Adjustment
1 Decrease 1 fc 2 Increase 1 fc
10 = Minimum On Time
1 0 min 3 30 min 5
2 15 min* 4 45 min
11 = Photocell Mode
P Option: 1 Full On/Off Ctrl* 2 Inhibit Only Ctrl
ADC Option: 1 Normal**
12 = Dual Technology (Microphonics
1 Normal* 2 Off 3 Medium
14 = Lamp Information
1
Enable LampMaximizer+
2 Disable LampMaximizer+*
3 Total Switches / 1000 4
4 Total Time On (khrs) 4
5 Reset Total Switch and Total Time On Statistics
6 Reset LampMaximizer+ Value
4
The LED will blink back a two digit value; the first digit, then pause,
then blink back the second digit. For a "0" the LED will blink rapidly.
15 = Dimming Range (High Trim)
1 Off 4 3 Volts 7 6 Volts
2 1 Volt 5 4 Volts 8 7 Volts
3 2 Volts 6 5 Volts 9 8 Volts
16 = Dimming Range (Low Trim)
1 Off 4 3 Volts 7 6 Volts
2 1 Volt* 5 4 Volts 8 7 Volts
3 2 Volts 6 5 Volts 9 8 Volts
* DEFAULT SETTING
** SPECIAL DEFAULT SETTING FOR -ADC, -D UNITS
*** SPECIAL DEFAULT SETTING FOR CM(R)B 6, CM(R)B 50,
CM(R) 6, RM(R) 6, RM(R) 50, SB(R) 6, & SB(R) 50 SERIES UNITS
60 min
2 Dim Only (No Off)
)
TM
4 Low
10 9 Volts
11 10 Volts*
10 9 Volts
11 10 Volts
