High-Resolution IR Camera
User Manual
If you have any questions, please call
W Box Tech Support 1-833-574-9124
for assistance.
E-mail：tech@wboxsupport.com

Advertisement

Table of Contents
loading

Related Manuals for WBOX Technologies 0E-13D28

Summary of Contents for WBOX Technologies 0E-13D28

  • Page 1 High-Resolution IR Camera User Manual 0E-13D28 0E-13BF36 If you have any questions, please call W Box Tech Support 1-833-574-9124 0E-21D28WDR for assistance. 0E-21BF36WDR E-mail：tech@wboxsupport.com 0E-40D28WDR 0E-40BF36WDR...
  • Page 3 High-Resolution IR Camera User Manual Hardware Connection Precautions Precautions Fully understand this document before using this device, and strictly observe rules in this document when using this device. If you install this device in public places, provide the tip "You have entered the area of electronic surveillance" in an eye- catching place.
  • Page 4 High-Resolution IR Camera Hardware Connection User Manual  Strictly conform to local electrical safety standards and use power adapters that are marked with the LPS standard when installing and using this device. Otherwise, this device may be damaged.  Use accessories delivered with this device. The voltage must meet input voltage requirements for this device.
  • Page 5 High-Resolution IR Camera User Manual Hardware Connection Special Announcement All complete products sold by the manufacturer are delivered along with nameplates, operation instructions, and accessories after strict inspection. The manufacturer shall not be held responsible for counterfeit products. This manual may contain misprints, technology information that is not accurate enough, or product function and operation description that is slightly inconsistent with the actual product.

  • Page 6: Table Of Contents

    High-Resolution IR Camera Hardware Connection User Manual Contents 1 Hardware Connection ..................... 6 2 Eyeball Camera......................7 2.1 Dimensions ........................7 2.2 Device Installation ......................7 3 Bullet camera ......................11 3.1 Dimensions ........................11 3.2 Device Installation ......................12 4 Web Operation .......................
  • Page 7 High-Resolution IR Camera User Manual Hardware Connection 4.6.2 Configuring a Recording Directory ..............48 4.6.3 Configuring the SD Card or NAS Recording ........... 50 4.7 Configuring the Privacy Mask Function ............... 51 4.8 Configuring the Network Service ................. 53 4.8.1 Setting 802.1x Parameters ................53 4.8.2 Setting DDNS Parameters ................

  • Page 8: Hardware Connection

    High-Resolution IR Camera Hardware Connection User Manual Hardware Connection Figure 1-1 shows the power and network cables. Figure 1-1 Power and network cables Table 1-1 shows the description of the cable. Table 1-1 description of the cable Core Description Network access port Connects to a standard Ethernet cable.

  • Page 9: Eyeball Camera

    Eyeball Camera Eyeball Camera 2.1 Dimensions Figure 2-1 shows the camera dimensions of 0E-13D28 and 0E-21D28WDR. Figure 2-1 Dimensions of 0E-13D28 and 0E-21D28WDR (unit: mm) Figure 2-2 shows the camera dimensions of 0E-40D28WDR. Figure 2-2 Dimensions of 0E-40D28WDR (unit: mm) 2.2 Device Installation...
  • Page 10 High-Resolution IR Camera Eyeball Camera User Manual Figure 2-3 Camera components Step 2 Use the base as drill template, drill holes on the ceiling or wall, and reserve the cable entries of the video/power cables. Figure 2-4 and Figure 2-5 shows the dimensions of the camera mounting base. Figure 2-4 Dimensions of the 0E-HDD1MP28 and 0E-HDD2MP28 mounting base Issue V1.0 (2018-05-11)
  • Page 11 High-Resolution IR Camera User Manual Eyeball Camera Figure 2-5 Dimensions of the 0E-HDDMO2812 mounting base Step 3 Nail swell plastic buttons in to drilled holes, and fix the camera mounting base to the ceiling (or wall) by use of self-tapping screws. Step 4 Install the compression ring, the dome shell, and the dome shell fixed base on the camera mounting base.
  • Page 12 High-Resolution IR Camera Eyeball Camera User Manual  Connect the BNC connector of the power or video cable to a video signal cable and connect the other connector to a low-voltage power cable. After installing the camera, directly connect the video cable and power cable. ...

  • Page 13: Bullet Camera

    High-Resolution IR Camera User Manual Bullet camera Bullet camera 3.1 Dimensions Figure 3-1 shows the dimensions of 0E-40BF36WDR. Figure 3-1 dimensions of 0E-40BF36WDR Figure 3-2 shows the dimensions of 0E-13BF36 and 0E-21BF36WDR. Issue V1.0 (2018-05-11)

  • Page 14: Device Installation

    High-Resolution IR Camera Bullet camera User Manual Figure 3-2 dimensions of 0E-13BF36 and 0E-21BF36WDR 3.2 Device Installation Step 1 Stick the Installation location sticker on the ceiling or wall, Drill three holes based on the marks on the sticker. Drive the swell plastic buttons into the holes, as shown in Figure 3-3.
  • Page 15 High-Resolution IR Camera User Manual Bullet camera Figure 3-4 Installing camera Step 3 Connect the Power and video cable, as shown in Figure 3-5. Figure 3-5 Connecting cable Step 4 Loosen the locking screw with L-Hex Wrench, rotate the camera to adjust the position and image so that the camera faces the monitored area, then tighten the locking screw, as shown in Figure 3-6.
  • Page 16 High-Resolution IR Camera Bullet camera User Manual Figure 3-6 Adjusting monitored area ----End Issue V1.0 (2018-05-11)

  • Page 17: Web Operation

    High-Resolution IR Camera User Manual Web Operation Web Operation 4.1 Quick start 4.1.1 Login and Logout You must use Internet Explorer 7, and more to access the web management system; otherwise, some functions may be unavailable. Login Step 1 Open Internet Explorer, enter the IP address of the IP camera (default value: 192.168.1.64) in the address box, and press Enter.

  • Page 18: Changing The Password

    High-Resolution IR Camera Web Operation User Manual  The default user name is admin. The default password is admin.  Change the password to ensure system security.  You can change the system display language on the login page. Step 3 Click The main page is displayed.

  • Page 19: Main

    High-Resolution IR Camera User Manual Web Operation Figure 4-3 Change the password page Step 1 Enter the old password, new password, and confirmation password. Step 2 Click OK. If the message "Change password success" is displayed, the password is successfully changed.
  • Page 20 High-Resolution IR Camera Web Operation User Manual Figure 4-4 Main page layout Table 4-1 Elements on the main page Element Description Real-time video Real-time videos are played in this area. You can also set area sensor parameters. Playback You can query the playback videos in this area. NOTE Only when the SD card or NAS have videos that you can query the playback videos.

  • Page 21: Browsing Real-Time Videos

    High-Resolution IR Camera User Manual Web Operation Fault icon When the device encounters an exception, the fault icon is displayed. You can click the icon to view the fault information. Change password You can click to change the password. Sign Out You can click to return to the login page.
  • Page 22 High-Resolution IR Camera Web Operation User Manual ----End Description To browse real-time videos, click Live Video. The Live Video page is displayed, as shown in Figure 4-6. Figure 4-6 Live Video page On the Live Video page, you can perform the following operations: ...

  • Page 23: Configuring The Device

    High-Resolution IR Camera User Manual Web Operation  Configure the sensor. You can right-click in the video area. A shortcut menu is displayed and allows you to enter the full-screen mode, set sensor parameters, zoom in or out, and return to the default view.
  • Page 24 High-Resolution IR Camera Web Operation User Manual Figure 4-7 Device Info page Step 2 View the device information, set the device ID and name according to Table 4-2. Table 4-2 Device parameters Parameter Description Setting Device ID Unique device identifier used by the [Setting method] platform to distinguish the devices.

  • Page 25: Setting Video And Audio Stream Parameters

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Hardware Version Firmware Version Video Channel(s) Channel Quantity Alarm Input Quantity Alarm Output Quantity Serial Port Quantity Network card Quantity Step 3 Click  If the message "Apply success!" is displayed, click OK. The system saves the settings.
  • Page 26 High-Resolution IR Camera Web Operation User Manual Figure 4-8 Stream Configuration page Step 2 Set the parameters according to Table 4-3. Table 4-3 Stream configuration parameters Parameter Description Setting Stream ID The device supports 3 streams. [Setting method] Select a value from the ...
  • Page 27 High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Video Encode The video codec determines the image [Setting method] Type quality and network bandwidth required Select a value from the by a video. Currently, the following drop-down list box. codec standards are supported: [Default value] ...
  • Page 28 High-Resolution IR Camera Web Operation User Manual Parameter Description Setting drop-down list box.  G711_ULAW: mainly used in North America and Japan.  G711_ALAW: mainly used in Europe and other areas.  RAW_PCM: codec of the original audio data. This codec is often used for platform data.

  • Page 29: Setting Svc Stream Parameters

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting The bit rate changes according to the image complexity. encoding efficiency is high and the definition of motion images can be ensured. Rate(500- Indicates the value of the bit rate. [Setting method] 12000) Enter a value manually.

  • Page 30: Region Of Interest

    High-Resolution IR Camera Web Operation User Manual Parameter Description Setting down list box. [Default value] SVC Stream Name Stream name. [Setting method] Enter a value manually. The NOTE value cannot exceed 32 The stream name is combined bytes. with Chinese character, number, [Default value] character and underline.
  • Page 31 High-Resolution IR Camera User Manual Web Operation Figure 4-10 ROI Configuration page Step 2 Set the parameters according to Table 4-5 Table 4-5 ROI configuration parameters Parameter Description Setting Stream Stream ID. [Setting method] Select a value from the drop-down list box. [Default value] Stream1 Enable...

  • Page 32: Setting Local Network Parameters

    High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Area ID ROI area ID [Setting method] Select a value from the drop-down list box. [Default value] Level Visual effect of ROI. The higher the [Setting method] grade is, the more clearly areas inside and Select a value from the the vaguer areas outside are..
  • Page 33 High-Resolution IR Camera User Manual Web Operation Figure 4-11 Local Network page Step 2 Set the parameters according toTable 4-6. Table 4-6 Local network parameters Parameter Description Setting IP Protocol IPv4 is the IP protocol that uses an [Setting method] address length of 32 bits.
  • Page 34 High-Resolution IR Camera Web Operation User Manual Parameter Description Setting IP Address Device IP address that can be set as [Setting method] required. Enter a value manually. [Default value] 192.168.1.64 Subnet Mask Subnet mask network [Setting method] adapter. Enter a value manually. [Default value] 255.255.255.0 Default...

  • Page 35: Configuring Device Ports

    High-Resolution IR Camera User Manual Web Operation 4.4.5 Configuring Device Ports Description You must configure the HTTP port, control port, Real Time Streaming Protocol (RTSP) port and RTMP port for device route mapping in a LAN. Procedure Step 1 Choose Configuration > Device > Device Port. The Device Port page is displayed, as shown in Figure 4-12.

  • Page 36: Configuring The Date And Time

    High-Resolution IR Camera Web Operation User Manual It’s not recommended to modify the control port, for details about the value ranges of the control port, HTTP port and RTSP port, see the communication matrix. Step 3 Click Apply.  If the message "Apply success!" is displayed, and the system saves the settings. ...
  • Page 37 High-Resolution IR Camera User Manual Web Operation Figure 4-13 Date and Time page Table 4-8 Date and Time parameters Parameter Description Setting Time Zone [Setting method] Select a value from the drop-down list box. [Default value] Greenwich mean time Issue V1.0 (2018-05-11)
  • Page 38 High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Daylight Saving When the DST start time arrives, [Setting method] Time the device time automatically goes Click the button on to forward one hour. When the DST enable Daylight Saving end time arrives, the device time Time.

  • Page 39: Setting The Channel Name, Video System, And Source Resolution

    High-Resolution IR Camera User Manual Web Operation Step 2 Select a time zone from the Time Zone drop-down list box. Step 3 (Optional) Click the button on to enable Daylight Saving Time and specify the DST start time and end time. Step 4 Modify the device time.

  • Page 40: Setting Osd Parameters

    High-Resolution IR Camera Web Operation User Manual Table 4-9 Camera parameters Parameter Description Setting Channel Name Channel name within the [Setting method] length of 0 to 32 bytes. Enter a value manually. Video System The options are as follows: [Setting method] Select a value from the ...
  • Page 41 High-Resolution IR Camera User Manual Web Operation  When the resolution is D1 and CIF, the OSD customized in web interface can show at most 22 words normally.  The OSD support simplified Chinese, English, digital and some special character only.
  • Page 42 High-Resolution IR Camera Web Operation User Manual  If the resolution is 1920 x 1080 and the size of each character is 48 x 48, then the maximum row of OSD is 22 (1080/48), and the maximum column is 40 (1920/48); ...

  • Page 43: System Service

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting back. Click the button on to enable Font on lighted back. Indicates whether [Setting method] Device Name display the device name. Click the button on to enable Device Name Step 3 Click Apply.

  • Page 44: Configuring The Alarm Function

    High-Resolution IR Camera Web Operation User Manual Step 7 Click OK, the device restarts and saves the settings automatically. ----End 4.5 Configuring the Alarm Function 4.5.1 Setting Disk Alarm Parameters Procedure Step 1 Choose Configuration >Alarm > Disk Alarm. The Disk Alarm page is displayed, as shown in Figure 4-17. Figure 4-17 Disk Alarm page Step 2 Click the button on to enable disk alarm.

  • Page 45: Setting Motion Alarm Parameters

    High-Resolution IR Camera User Manual Web Operation Figure 4-18 Network Alarm page Step 2 Click the button on to enable exceptional alarm. Step 3 Configure the network exceptional alarm interval. Step 4 Tick the Output Channel number. Step 5 Click the button on to enable Alarm Record alarm. Step 6 Click Apply.
  • Page 46 High-Resolution IR Camera Web Operation User Manual  Enable FTP Upload. Procedure Step 1 Choose Configuration >Alarm > Motion Alarm. The Motion Alarm page is displayed, as shown in Figure 4-19. Figure 4-19 Motion Alarm page Step 2 Click the button on to enable motion alarm. Step 3 Configure the motion interval.

  • Page 47: Setting Push Message Parameters

    High-Resolution IR Camera User Manual Web Operation NOTE When you select time by dragging the cursor, the cursor cannot be moved out of the time area. Otherwise, no time can be selected. Method 3：Click in the schedule page to select the whole day or whole week. Deleting deployment time: Click again or inverse selection to delete the selected schedule.

  • Page 48: Configuring The Recording Function

    High-Resolution IR Camera Web Operation User Manual Procedure Step 1 Choose Configuration >Alarm > Push Message. The Push Message page is displayed, as shown in Figure 4-21. Figure 4-21 Push message page Step 2 Click the button on to enable push message. Step 3 Click Apply.
  • Page 49 High-Resolution IR Camera User Manual Web Operation Figure 4-22 Record Policy page Step 2 Set the parameters according to Table 4-11. Table 4-11 Recording policy parameters Parameter Description Setting Schedule Enables schedule record that you can [Setting method] Record configure the time policy. Click the button on to enable schedule record.

  • Page 50: Configuring A Recording Directory

    High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Stream Name of the stream. [Setting method] Name Select a value from the drop- down list box. Step 3 Configure a recording plan. You can configure the system to record videos around the clock or in schedule. For details about how to set Schedule, see 4.5.3 Step 5.
  • Page 51 High-Resolution IR Camera User Manual Web Operation Figure 4-23 Record Directory page Step 2 Set the parameters according to Table 4-12. Table 4-12 Recording directory parameters Parameter Description Setting Disk Type Recording directory type, which can be a [Setting method] NAS.

  • Page 52: Configuring The Sd Card Or Nas Recording

    High-Resolution IR Camera Web Operation User Manual 4.6.3 Configuring the SD Card or NAS Recording Procedure Step 1 Choose Configuration > Device Record > Record Directory. Step 2 Click Modify. The Record Path Modify page is displayed, as shown in Figure 4-24. Figure 4-24 SD card Record Path Modify page Step 3 Set the parameters according to Table 4-13.

  • Page 53: Configuring The Privacy Mask Function

    High-Resolution IR Camera User Manual Web Operation Step 4 Click Apply. The message "Apply success!" is displayed, and the system saves the settings. -----End 4.7 Configuring the Privacy Mask Function Procedure Step 1 Choose Configuration > Privacy Masking. The Privacy Masking page is displayed, as shown in Figure 4-25. Figure 4-25 Privacy Masking page Step 2 Press and hold the left mouse button, and drag on the preview image to cover the part...
  • Page 54 High-Resolution IR Camera Web Operation User Manual  The maximum percentage of an image that can be masked depends on the device model. Read the tip displayed on the page. A maximum of five areas can be masked.  You can click Reset to configure the masked areas again. Step 3 Set the parameters according to Table 4-14.

  • Page 55: Configuring The Network Service

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Modify Modify a privacy masking. [Setting method] Select a privacy masking from the Privacy Masking List. Click a parameter and modify it. Click Modify, privacy masking modified successfully Step 4 Click Apply.

  • Page 56: Setting Ddns Parameters

    High-Resolution IR Camera Web Operation User Manual Step 2 Click the button on to enable 802.1x. Step 3 Enter the account name. Step 4 Enter the password and confirm password.. Step 5 Click Apply. Step 6 The message "Apply success!" is displayed, and the system saves the settings. ----End 4.8.2 Setting DDNS Parameters Preparation...

  • Page 57: Setting Pppoe Parameters

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Provider DDNS service provider. [Setting method] Currently, only 3322 and Select a value from the drop-down DynDns are supported. list box. [Default value] WBoxDDNS NOTE Set this parameter based on the site requirements.

  • Page 58: Setting Port Mapping Parameters

    High-Resolution IR Camera Web Operation User Manual Figure 4-28 PPPoE page Step 2 Click the button on to enable PPPoE. Step 3 Set the parameters according to Table 4-16. Table 4-16 PPPoE parameters Parameter Description Setting PPPoE Indicates whether to enable the [Setting method] PPPoE service.
  • Page 59 High-Resolution IR Camera User Manual Web Operation Procedure Step 1 Choose Configuration > Network Service > Port Mapping. The Port Mapping page is displayed, as shown in Figure 4-29. Figure 4-29 Port Mapping page Step 2 Click the button on to enable Port Mapping. Step 3 Set the parameters according to Table 4-17.

  • Page 60: Setting Smtp Parameters

    High-Resolution IR Camera Web Operation User Manual Outside Port Port of outside network. [Setting method] Enter a value manually in map mode. Outside IP Address IP address of outside network. State Mapping status Step 4 Click Apply.  If the message "Apply success!" is displayed, and the system saves the settings. ...
  • Page 61 High-Resolution IR Camera User Manual Web Operation Figure 4-30 SMTP page Step 2 Set the parameters according to Table 4-18. Parameters marked with are mandatory. Table 4-18 SMTP parameters Parameter Description Setting SMTP Server IP address of the SMTP server. [Setting method] Address Enter a value manually.

  • Page 62: Setting Ftp Parameters

    High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Sender Mailbox for sending emails. [Setting method] mail Address Enter a value manually. Recipient_E- (Mandatory) Email address of recipient [Setting method] mail_Address Enter a value manually. Recipient_E- (Optional) Email address of recipient 2. mail_Address Recipient_E- (Optional) Email address of recipient 3.
  • Page 63 High-Resolution IR Camera User Manual Web Operation The FTP page is displayed, as shown in Figure 4-31. Figure 4-31 FTP page Step 2 Click the button on to enable FTP. Step 3 Set the parameters according to Table 4-19. Table 4-19 FTP parameters Parameter Description Setting...

  • Page 64: Setting Ip Filter Parameters

    High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Image A higher-quality image means [Setting method] Quality more storage space. Set this Select a value from the drop- parameter based on the site down list box. requirement. [Default value] Step 4 Click Apply.
  • Page 65 High-Resolution IR Camera User Manual Web Operation Figure 4-32 IP Filter page Step 2 Click the button on to enable IP Filter. Step 3 Set the parameters according to Table 4-20 Table 4-20 IP Filter parameters Parameter Description Setting IP Filter Indicates whether to enable the [Setting method] IP Filter.
  • Page 66 High-Resolution IR Camera Web Operation User Manual Parameter Description Setting Black List Specified network segment to [Setting method] allow access Click to enter the add black/white list page, as shown in Figure 4-33 Enter Begin IP Address. Enter End IP Address. Enter Description.

  • Page 67: Setting Cgi Alarm Service Center Parameters

    High-Resolution IR Camera User Manual Web Operation Figure 4-33 Add IP Filter page Step 4 Click Apply. The message "Apply success!" is displayed, and the system saves the settings. ----End 4.8.8 Setting CGI Alarm Service Center Parameters Description Device will push the alarm message by CGI with Start URL and End URL, and send to data to CGI Server by HTTP protocol.
  • Page 68 High-Resolution IR Camera Web Operation User Manual Figure 4-34 CGI Alarm Service Center page Step 2 Click the button on to enable CGI Alarm. Step 3 Set the parameters according to Table 4-21. Table 4-21 CGI Alarm Service Center parameters Parameter Description Setting...
  • Page 69 High-Resolution IR Camera User Manual Web Operation Parameter Description Setting URL Start Push the alarm message by CGI [Setting method] with start URL Enter a value manually. For example: http://192.168.35.74:80/MajorAlar mType&MinorAlarmType&Source Name&DeviceID&DeviceIP&Alar mTime& Description URL End Push the alarm message by CGI [Setting method] with end URL Enter a value manually.

  • Page 70: Setting Snmp Parameters

    High-Resolution IR Camera Web Operation User Manual The message "Apply success!" is displayed, and the system saves the settings. ----End 4.8.9 Setting SNMP Parameters Description Simple Network Management Protocol (SNMP) is an Internet Standard protocol, supports SNMP v1, SNMPv2c and SNMPv3 network protocol. Choose the proper SNMP protocol version and set the SNMP protocol parameter to collect and organize information about managed devices on IP networks.
  • Page 71 High-Resolution IR Camera User Manual Web Operation Figure 4-35 SNMP page Step 2 Click the button on to enable SNMPv1, SNMPv2C and SNMPv3. Table 4-22 Set the parameters according to Table 4-23. Issue V1.0 (2018-05-11)
  • Page 72 High-Resolution IR Camera Web Operation User Manual Table 4-23 SNMP parameters Parameter Description Setting SNMPv1 Version of SNMP. [Setting method] SNMPv1 and SNMPv2c use communities to Click the button on. establish trust between managers and agents. [Default value] SNMPv2c Agents support three community names, write community, read community and trap.

  • Page 73: Privilege Manager

    High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Auth Authentication password. [Setting method] Password Enter a value manually. Encry Encryption Algorithm, includes DES and [Setting method] Algorithm AES. Select a value from the drop-down list box. [Default value] Blank Encry Encryption password.
  • Page 74 High-Resolution IR Camera Web Operation User Manual Figure 4-36 User page Table 4-24 User parameters Parameter Description Setting User ID User Name User name for logging in to the camera. [Setting method] Select a value from the drop-down list box. Groups Permission group where a user belongs.
  • Page 75 High-Resolution IR Camera User Manual Web Operation Parameter Description Setting Notes Notes of the User. [Setting method] Click Add, then enter a value manually. Operate The operation of the user, includes view [Setting method] user, modify user and delete user. Click icon required.
  • Page 76 High-Resolution IR Camera Web Operation User Manual Function Procedure Description Delete Delete a user. Select the user from the User list. Click , the message “Confirm to delete?” is displayed, click OK, then the group is deleted successfully. Figure 4-37 Add user page ----End Issue V1.0 (2018-05-11)

  • Page 77: Configuring Protocol Parameters

    High-Resolution IR Camera User Manual Web Operation 4.10 Configuring Protocol Parameters 4.10.1 Checking Protocol Information Description You can view the existing protocol name and version number of the current device on the Configuration > Protocol > Protocol Info page, as shown in Figure 4-38. Table 4- 26 describes the protocol-related parameters.

  • Page 78: Setting Multicast Parameters

    High-Resolution IR Camera Web Operation User Manual Procedure Step 1 Choose Configuration > Protocol > Security. The Security page is displayed as shown in Figure 4-39. Table 4-27 describes the parameters on the Security page. Figure 4-39 Security page Table 4-27 Parameter description Parameter Description Setting...
  • Page 79 High-Resolution IR Camera User Manual Web Operation Figure 4-40 Multicast Param page Table 4-28 Parameter description Parameter Description Setting Stream ID ID of stream. [Setting method] Select a value from the drop- list box. [Default value] IP address that receive multicast data. [Setting method] Enter a value manually.

  • Page 80: Querying Operation Logs

    High-Resolution IR Camera Web Operation User Manual 4.11 Querying Operation Logs Description Operation logs record user operations and scheduled task commands during the running of the device. Operation logs can be classified into the following types: permission management, system maintenance, device configuration, recording operation, video control, and real-time video.

  • Page 81: Querying Alarm Logs

    High-Resolution IR Camera User Manual Web Operation Set the start time and end time as required. Enter the corresponding user name that is registered with the device from the User Name drop-down list box. Step 3 Click Query. The operation logs related to the specified user are displayed. Step 4 Download the operation logs.
  • Page 82 High-Resolution IR Camera Web Operation User Manual Figure 4-42 Alarm Log page Step 2 Set the search criteria. Click the Begin Time and End Time text boxes respectively. A time setting control is displayed. Set the start time and end time as required. Select the type of the alarm logs to be queried from the Alarm Type drop-down list box.

  • Page 83: Reporting Logs

    High-Resolution IR Camera User Manual Web Operation For example: 2012-03-17 16:31:17 -> 2012-03-17 16:32:29 occur motion detect alarm SourceId(1:1) 2012-03-17 16:35:31 -> 2012-03-17 16:35:41 occur motion detect alarm SourceId(1:1) ----End 4.11.4 Reporting Logs Description You can collect logs about a device, which help you analyze and solve possible problems occurring on the device.

  • Page 84: Updating The Software Package

    High-Resolution IR Camera Web Operation User Manual Procedure Step 1 Choose Configuration > Maintenance. The Camera Maintenance page is displayed, as shown in Figure 4-44. Figure 4-44 Camera Restart page Step 2 Click The message "Are you sure to restart?" is displayed. Step 3 Click OK.

  • Page 85: Restoring A Device To Factory Settings

    High-Resolution IR Camera User Manual Web Operation 4.12.3 Restoring a Device to Factory Settings Description You can restore a device to factory settings in situations including the following:  The device parameters are set incorrectly, and the device cannot work properly. ...
  • Page 86 High-Resolution IR Camera Web Operation User Manual Figure 4-45 Local Config page Step 2 Select snapshot picture format from the drop-down box.. Step 3 Set snapshot save path. Step 4 Set local record save path Step 5 Set local record file size(8-128M), the default value is 64. Step 6 The message "Apply success!"...

  • Page 87: Technical Specifications

    High-Resolution IR Camera User Manual Technical Specifications Technical Specifications Table 5-1 lists the technical specifications of the camera. Table 5-1 Technical specifications Specifications 0E-21D28WDR 0E-21BF36WDR CAMERA 1/2.7” Progressive Scan CMOS Image Sensor Color :0.2Lux@(F1.2,AGC ON) Min. illumination B/W: 0 Lux@(IR LED ON) Day &...
  • Page 88 High-Resolution IR Camera Technical Specifications User Manual Specifications 0E-21D28WDR 0E-21BF36WDR 9:16 Corridor mode Defog NETWORK IPv4,802.1x,HTTP,HTTPS,TCP/IP,UDP/IP,RTSP,DHCP, Network Protocols: NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ICMP, IGMP, Unicast and Multicast Alarm Trigger Motion Detection, Network Disconnect, Disk Alarm RTSP Video Standard RFC2326, Support QuickTime/VLC Player Security User security authentication, Reset, Hardware Watch Dog...
  • Page 89 High-Resolution IR Camera User Manual Technical Specifications Specifications 0E-13D28 0E-13BF36 CAMERA 1/2.7” Progressive Scan CMOS Image Sensor Color :0.2Lux@(F1.2,AGC ON) Min. illumination B/W: 0 Lux@(IR LED ON) Day & Night Shutter Speed 1/1-1/10000 Auto Iris Fixed Wide Dynamic Range dWDR...
  • Page 90 High-Resolution IR Camera Technical Specifications User Manual Specifications 0E-13D28 0E-13BF36 IPv4,802.1x,HTTP,HTTPS,TCP/IP,UDP/IP,RTSP,DHCP, Network Protocols NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ICMP ,IGMP, Unicast and Multicast Alarm Trigger Motion Detection, Network disconnect, Disk alarm RTSP Video Standard RFC2326, Support QuickTime / VLC Player.
  • Page 91 High-Resolution IR Camera User Manual Technical Specifications Specifications 0E-40D28WDR 0E-40BF36WDR CAMERA 1/3” Progressive Scan CMOS Image Sensor Color :0.05Lux@(F1.2,AGC ON) Min. illumination B/W: 0 Lux@(IR LED ON) Day & Night Shutter Speed 1/5-1/20000 Auto Iris Fixed Wide Dynamic Range WDR >120dB Digital Noise Reduction 2D/3D Lens...
  • Page 92 High-Resolution IR Camera Technical Specifications User Manual Specifications 0E-40D28WDR 0E-40BF36WDR IPv4,802.1x,HTTP,HTTPS,TCP/IP,UDP/IP,RTSP,DHCP, Network Protocols NTP, RTCP/RTP, PPPoE, SMTP, DNS, UPnP, FTP, ICMP, IGMP, Unicast and Multicast Alarm Trigger Motion Detection, Network Disconnect, Disk Alarm RTSP Video Standard RFC2326, Support QuickTime/VLC Player. Security User security authentication, Reset, Hardware Watch Dog English, Chinese, Polish, Italian, Portuguese, Spanish.
