AOX -800DD User Manual

HOW TO CHANGE THE FILTERS?

1. Turn off the tap and open the cover (Photo E)
2. Turn on the 800DD tap to let out the excess water
3. Remove the filters from the chamber by pulling it out gently.
4. Using the tube remover, place it over the connector ring (photo F), push in the connector
ring and hold it there. Pull out the connecting tube gently.
5. Following the same sequence as when you remove the filters, insert the new set of filters
accordingly. Ensure that the tubes are secure by giving them a slight tug to see if it
comes off.
6. Close the cover and turn on the tap and faucet for about 1 minute to flush the filters
thoroughly
7. After flushing, the dispenser is ready for use.
Photo E

REPLACEMENT OF FILTERS

1. Please pay attention to the arrow mark of filters when you are changing your filters (Diagram 1).
Optimal lifespan:
2.
In order to ensure maximum efficiency and purity of the water, it is recommended that you
change your filters every 12 months.
The usage is also determined by the incoming water source. If the incoming water has more
suspended particles, it may cause the filters to "choke" before the recommended date.
CAUTION:
3.
DO NOT USE where water is microbiologically unsafe or of unknown quality without adequate
disinfection.
SHUT OFF THE WATER VALVE - whenever the water dispenser is left unattended overnight on
weekends or on holiday. This will prevent the water pressure from building up over time which
may cause accidental leakages or choking.
Maximum pressure:
4.
120 PSI
Photo F
Multi-Award Winning Brand
User's Manual

SPECIFICATIONS

Dimension (cm): 40L x 9B x 32.5H
Net Weight: 2.0kg
Gross Weight: 2.4kg
Multi-Award Winning Brand
AOX-800DD
is designed to remove
Coliform Bacteria,
Chlorine, THM, Carcinogens,
Fluoride and Heavy Metals
such as Lead, Mercury,
Arsenic, Barium, Cadmium.
Flow rate: 90 - 120 litre/hr
Pressure: 120 PSI
AOX Pte Ltd
www.AOX.com.sg
28 Sin Ming Lane sales@aox.com.sg
#03-143 Midview City
6456 4321
Singapore 573972
