- Page 1 AP0158770 5 GHz Wireless Module REFERENCE GUIDE...
-
Page 2: Regulatory Compliance
Resellers or distributors of this equipment are not liable for injury, damage or violation of regulations associated with the installation of outdoor units or antennas. The installer should configure the output power level of antennas according to country regulations and antenna type. AP0158770 Reference Guide... - Page 3 2. Cet appareil doit accepter toute 3nterference, y compris les 3nterferences qui peuvent causer un mauvais fonctionnement de l’appareil. This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numrique de la classe B est conforme la norme NMB-003 du Canada AP0158770 Reference Guide...
- Page 4 Overview The AP0158770 is a wireless module operating in the 4.9, 5.1, 5.3, 5.4 and 5.8 GHz frequency bands. It is a TDD OFDM radio supporting 5 MHz, 10 MHz, 20 MHz, 40 MHz and 80 MHz channel bandwidths. The wireless module cannot work as a stand-alone device. It can operate and be controlled only when attached to a digital main board and altogether assembled in an enclosure suitable for outdoor use.
- Page 5 Antennas Following is the list of antennas supported by the AP0158770 5 GHz Wireless Module: Antenna Max Antenna Type Manufacturer Model Number Gain (dBi) Sector Dual Pole Integrated 120 Deg RADWIN Ltd. MT0128930 Sector Dual Pole 120 Deg RADWIN Ltd.
- Page 6 The following parameters can be accessed by user: 1. Output Power 2. Frequency channel 3. Channel bandwidth 4. Antenna gain in external antenna type device * Under IC regulations the 5600-5650 MHz band is excluded from operation AP0158770 Reference Guide...
