MicroNet SP5591A Quick Installation Manual

Ceiling/Wall Mounting

Follow the steps below to install the IP Camera:
Step 1: Unpack the Bullet IP Camera package and take out the
Step 1: IP Camera.
Step 2: Connect the power/Ethernet/alarm/audio wires from ceiling
Step 1: or wall to the corresponding connectors of the camera's
Step 1: All-in-one Cable.
Step 3: Fix the IP Camera's Bracket on the
Step 3: ceiling/wall with supplied self
Step 3: tapping screws
Step 4: Use the supplied Inner Hex Wrench and
Step 3: cross screwdriver to loosen the hex
Step 3: bolt/screw on the side of the Bracket
Step 3: Mount and the Camera Housing to
Step 3: adjust the position of the IP Camera.

Lens Adjustment

Step 1: Unscrew the screw on the Camera
Step 1: Housing and remove the Front Housing.
Step 2: Connect the power/Audio/alarm,
Step 1: I/O wires to the matching connectors.
Step 3: Access the Camera Browser-viewer for viewing images.
Step 4: Adjust the Zoom/ Focus Ring Screw on the lens to set the
Step 1: desired zoom/ focal length.
Login ID & Password
Key in the Bullet IP Camera's IP address in the URL bar of the
Web browser window and press "Enter."
Enter the default user name (root) and password (pass) in the
prompt request dialogue. Note that user name is case sensitive.

Install the ActiveX control

After connecting to the Bullet IP Camera, the request for installing
the ActiveX control will appear just below the URL bar.
Right Click on the information bar, and press "Install ActiveX
Control..."to permit ActiveX control installation.
In the pop-up security
warning window, click "Install"
to start downloading DC
Viewer software on the PC.
Press "Finish" after DC
Viewer installation
is complete.

Browser-based Viewer

The main page of the Bullet IP
Camera user interface is as
shown below. Please note that
the function buttons will vary
depending on the camera model.
WEEE Directive & Product Disposal
At the end its serviceable life ,this product should not be treated as
household or general waste. It should be handed over to the applicable
collection point for the recycling of electrical and electronic equipment, or
returned to the supplier for disposal.
P/N 2300-0740
5
7
Step 2: Before Login to the Bullet IP Camera
A client program will be automatically installed on your PC when
connecting to the Bullet IP Camera. Before logging in to the Bullet
IP Camera, please ensure downloading the ActiveX control is
allowed by either changing the ActiveX controls and plug-ins or
setting Internet's security level to default. For further details, please
refer to the Bullet IP Camera's user manual.
ActiveX Controls and Plug-ins
Settings
Step 1: Start the Internet Explorer (IE).
Step 2: Select <Tools> from the main
Step 2: menu of the browser. Then
Step 2: Click <Internet Options>.
Step 3: Click the <Security> tab and
Step 2: select "Internet", and click
Step 2: <Custom level> to change
Step 2: ActiveX settings.
Step 4: Set "ActiveX controls and
Step 2: plug-ins" items to <Prompt>
Step 2: or <Enable>.
Step 3: Bullet IP Camera Login
The Bullet IP Camera's default IP address is: 192.168.1.2.
Therefore, to access the Bullet IP Camera for the first time, set the
PC's IP address as: 192.168.1.X; for example:
IP Address: 192.168.1.100
Subnet Mask: 255.255.255.0
Communicate via
Quick Installation Guide
1080p Full HD Bullet IP Camera
Model No.: SP5591A
Version 1.2

Internet Security Level

Step1: Start the IE.
Step 2: Select <Tools> from the main
Step 2: menu of the browser. Then
Step 2: Click <Internet Options>.
Step 3: Click the <Security> tab and
Step 2: select "Internet."
Step 4: Down the page, press
Step 2: "Default Level" and click "OK"
Step 2: to confirm the setting. Close
Step 2: the browser window, and
Step 2: open a new one later for
Step 2: accessing the Bullet
Step 2: IP Camera
6
