Summary of Contents for SUPER-CAN INDUSTRY GROWING GROUP CO.,LTD. LD706-54039F
- Page 1 Waterproof Flood Light Model: LD706-54039F Power Version USER’s MANUAL This product manual contains important information about safe installation and use of this product. Please read and follow this instruction carefully. Update:2017.12.09...
- Page 2 Understanding of Product Security Warning When unpacking and before disposing of the carton, check if there is any transportation damage before using the product. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. ...
- Page 3 Main Technical Parameters Power supply Rated Voltage: AC90~120V Rated Frequency: 50~60Hz ± 10% Rated Power: 200W LED Type: 54pcs ×3W RGB 3in1 LED Chips Drive Current: 700mA Lifespan: About 50000 hours Control Control Protocol: International standard DMX-512 signal ...
-
Page 4: Product Features
Product Features Using the latest LED control technique, newest intelligent LED Par light can realize intelligent operation and control through its special menu at the side of the body. It’s more convenient and easy to operate.This product is designed for building large area spread light,large concerts, outdoor landscape lighting, wedding scene, small performances, slow club KTV and various performance occasion. - Page 5 After electrical connection, this product will have a few seconds self-check action, self-check finished can be used. Input / output power cable should be 2.5 square millimeter copper core. 220V: 15 units may be connected in series. 110V: 7 units may be connected in series. Important: It is essential that Yellow/green double color wire is correctly earthed and that electrical installation conforms to all relevant standards.
-
Page 6: Menu Overview
Operation Method Menu Overview 3.2 Static Color Setting (STATIC) Find【STATIC】menu and press【ENTER】 to enter color static setting. Press【ENTER】button to select【RED】,【GREEN】,【BLUE】 Press【UP/DOWN】button to adjust parameters. Press【MENU】button to return to the menu, the selected parameters will be automatically saved. ... -
Page 7: Product Maintenance
3.4 DMX Code Setting (DMX) Find【DMX】menu and press【ENTER】to enter address code setting. Press【UP/DOWN】button to select DMX address code. Press 【ENTER】 to confirm or 【 MENU】 to exit, the selected address code will be automatically saved. 3.5 Temperature Control Protection State ... -
Page 8: Trouble Shooting
Trouble Shooting Problems Action Power connection is not correct--Re-connect it. The product doesn't Power supply is damaged or abnormal. Call a qualified personnel to fix it. switch on Control section is damaged. Call a qualified personnel to fix it. Connection of internal circuitry is not correct. Call a qualified personnel to fix it. DMX address is wrongly setting up.
