LR5011
TEMPERATURE LOGGER
Operation Manual
June 2013 Revised edition 2 Printed in Japan
LR5011B981-02 13-06H
1
Confirmation
Confirm package contents, and prepare needed items.
Logger and Accessories
Instruction manual
Refer to this manual for
LR5011
operating
details, or when prob-
lems occur.
LR6 alkaline battery
(Pre-installed in the log- Stand
ger.)
This is
stand. See the Instruc-
tion Manual for details.
Option
Example: LR9604
LR5091 Communication Adapter Temperature Sensor
(Includes LR5000 Utility Program (Please use Hioki-brand options.
See the Instruction Manual.)
CD [PC application software] and
USB Cable)

Importing data to a computer requires the optional LR5091
Communication Adapter or LR5092-20 Data Collector
3
Display Example: Setting the
recording interval to 10 minutes.

Settings

1
Display the settings, and select
the setting item.
2
Configure the setting as
needed.
3
Apply the new setting contents.
(The setting items are displayed as shown under Setting Display
on page 2.)
Stop
[REC] disappears when
Hold the button for two seconds
recording stops.
[REC]
while recording (while is displayed).
If the stop method is set
to [OFF], recording stops
Note: Continue pressing the button until the
automatically when mem-
[REC] indicator changes from a blinking
ory becomes full.
to off state.
Thank you for purchasing the HIOKI LR5011
Temperature Logger.
This guide introduces the logger's basic mea-
surement procedure to first-time users.
Before using the instrument, be sure to read the Instruc-
tion Manual carefully.
2

Preparations

Install the battery and connect the cable to the logger.
1

Installing the Battery

1
procedure
2
3
the logger
2
3
4
4

When the battery is installed, the logger
turns on (there is no power switch).

Connecting a Temperature Sensor

Align the triangles on the plug
body and in front of the sensor
jacks,
securely. (Insert the protruded
parts of the connecting cable
into the holes of the device.)

Temperature sensors are available as options. Select according
to your application.
4

Recording

Before recording, install the logger and perform
pre-measurement inspection.
(See the Instruction manual for details.)
Start
From the Measurement display, hold the
button for two seconds.
Note: Continue pressing the button until the
[REC] indicator changes from a blink-
ing to on state.
When the blinking stops and the data count is
zeroed, recording starts.
After one second, the measurement display
reappears.

Logger memory contains the data for two recording sessions. (Be
aware that old data is erased when starting recording after two record-
ing sessions.)

Data can be imported to a computer without stopping recording.
Setting Display

Read First

(Returns to the measuring display)
Recording Interval Setting
Press the PUSH tab as
shown, and pull the bat-
tery cover back.
Install the battery as
shown.
Year Setting
Align the holes in the
battery cover with the
projections on the back
of the logger.
While confirming that
Month Setting
there are no gaps, press
with your fingers to
close the battery cover.
Day Setting
Operating Buttons
and insert the plug
SET
Displays settings.
(-), (+)
Changes Measurement display contents.
Changes setting values on the Settings display.
REC/STOP
Hold for two seconds to start/stop recording.
From a setting display, switches to measurement display.
 Setting Display: Displays settings (recording interval, date
and time, etc.)
 Measuring Display: Displays recorded data (measured val-
ues, recorded data count, etc.)

Indicators

REC
Recording in progress
AL
Upper/lower threshold exceeded
ENDLESS
Stop method enabled
STAT
Recording mode enabled
MAX, MIN
Maximum and minimum values
DATA
Recorded data count
Measuring Display
Power Save Setting
Recording Mode Setting
 Power Save
Battery life is extended when on (enabled).
Stop Method Setting
Default is on.
 Recording Mode
When on (statistical recording), instantaneous, maximum, minimum, and aver-
age values are recorded at each interval. (Record statistical values) Battery life is
shorter.
Minute Setting Default is off.
 Stop Method
Select what happens when memory becomes full.
When on, the oldest data is overwritten (Endless Recording), and when off,
recording stops (One-Time Recording).
Default is on.
Hour Setting
Troubleshooting
 No measured value is displayed.
Is the sensor plug inserted all the way in?
Verify the correct plug orientation, and insert it as
far as possible.
If the values are not displayed despite these
measures, the sensor and logger need to be
inspected and repaired.
Please contact your dealer or Hioki representative.
Note: The maximum and minimum values are not displayed when the
recorded data count is 0.
 The display is blank.
Is auto power saving enabled (set to ON)?
When enabled, the display blanks after 30 seconds of operator inactivity.
Press any button or send a communication signal to turn on the display.
 The [REC] indicator disappears even though recording has not
been stopped.
Is the stop method disabled (set to OFF)?
With disabled, recording stops automatically when memory becomes full.
To record continuously until stopped by the REC/STOP button, enable the
stop method.
(In this case, old data is overwritten when the memory becomes full.)
Battery Status Indicator
 Recorded data has disappeared.
Does recording restart after stopping?
Note that if recording is accidentally restarted after stopping, data recorded
prior to the last recording is automatically erased.
(The logger retains the data from both current and most recent prior
recording operations.)
 To erase logger memory
Erase using the PC Utility program. See the Instruction manual for details.
 The battery is depleted too quickly.
Are you using the battery originally supplied with the logger?
Are you using a zinc-manganese battery?
Install a new AA-size (LR6) alkaline battery.
Measured value
Recorded data
count
Maximum value
Minimum value
