Summary of Contents for Corewise CR30
- Page 1 2014 CR30 User Manual USER MANUAL CR30 Nanjing Corewise Smart Technology Inc. Support Hotline: 0086-13851413726, 13851629242 Skype: xiafan_max(software), cruise.xiao (hardware) E-mail: bi.chuanrong@corewise.cn http://www.corewise.cn...
-
Page 2: Profile Picture
2014 CR30 User Manual Profile Picture Indicator Fingerprint Sensor USB Port RFID Reading Area Power On Button http://www.corewise.cn... - Page 3 2014 CR30 User Manual CR30 PCBA (Printed Circuit Board Assembly) Technical Specifications Technical Specifications Physical Indices Dimensions 152*87*27 (mm) Weight 300g RFID Parameters Reading Range 3~5 cm RFID Frequency 13.56Mhz, High Frequency RFID Protocol ISO/IEC 14443 Type B Biometric Parameters...
-
Page 4: Fingerprint Sensor
2014 CR30 User Manual Programming Tools Support VS etc I/O Ports 10-pin mini USB, RS232 Bluetooth BT2.0, 10m Battery 2000mAh, 3.7V Indicators Bluetooth Indicator When power on, Bluetooth indicator flashes in blue. If connected to other devices successfully via Bluetooth, then Bluetooth indicator remains light on. -
Page 5: Rfid (Radio-Frequency Identification)
2014 CR30 User Manual 8bits per pixel 8bits per pixel Lifetime 4M finger placements 4M finger placements Imaging Mode <=20mA @ 5.0V <=20mA @ 5.0V Standard IM 4.4V to 5.5V 4.4V to 5.5V Supply EIM Modes 4.5V to 4.6V 4.5V to 4.6V... - Page 6 CR30 User Manual Applications Our device CR30 can be connected to PC, mobile phones, desktop computers, UMPC and so on smart devices via USB cable or Bluetooth. It can be utilized in various scenarios, e.g. mobile attendance checking, identity verification for exams/driving tests/ insurance beneficiary, etc.
-
Page 7: Packing List
2014 CR30 User Manual The captured images in the device can be transmitted to other devices or backend server via USB cable or Bluetooth afterward. Packing List S.N. Items Unit Reader Device Charger Manual Warranty Card Piece http://www.corewise.cn...
