ikeGPS IKE 4 Setup Manual

Welcome to
The Evolution of Pole Measurements
7
6
5
1
11
WARNING This device contains an eye safe class 1M laser product.
Invisible laser radiation is emitted from (and received into) the front
apertures. Avoid staring into the laser beam. This product complies with
IEC60825-1 Ed 2.0 and 21CFR1040.10 except for deviations pursuant to
Laser Notice No.50, dated July 26 2001.
CAUTION Use of controls or adjustments, or performance of
procedures other than those specified herein may result in hazardous
radiation exposure.
1
Assemble
Setup Guide
Learn more at www.ikegps.com
1
4
3
2
9
3
4
1
2
10
3
4
5
6
IKE 4
1 IKE device
2 USB car charger
3 Power cable
4 Micro USB cable
5 AC charger with plug adapter
6 Screwdriver
7 Shoulder strap for hard case
8 Hard case (not shown)
An SD card is not included.
IMPORTANT: The IKE 4 device is
2
designed to be used with the IKE Tripod.
It should not be used while being held by
hand, or placed close to the user's body.
8
7
LCD display
Power button
Power port
USB port 10
Volume buttons 11
Flash
WARNING LASER RADIATION
DO NOT EXPOSE USERS OF TELESCOPIC OPTICS
CLASS 1M LASER PRODUCT
6
7 Camera
8 Laser receive lens
9 Laser transmit lens
Stylus pen thread
Tripod screw thread
5
