- Page 1 New England Toilet roll cupboard Assembly Instructions - please keep for future reference QN917 464/3944 Dimensions Width - 20cm Depth - 20cm Height - 80cm Important – Please read these instructions fully before starting assembly Issue 1 - 16/05/2016...
-
Page 2: Care And Maintenance
Safety and Care Advice Important – Please read these instructions fully before starting assembly • Check you have all the • During assembly do not stand • We do not components and tools listed on or put weight on the product, recommend the use page 2 this could cause damage. - Page 3 Components - Panels Please check you have all the panels listed below 2 x1 1 x1 20X20X1.2cm 20X20X1.2cm 77.7X18.5X1.2cm 77.7X18.5X1.2cm 7 x1 77X20X1.2cm 78.5X18.3X0.3cm 17.5x17X1.2cm Components - Fittings Note: may be supplied than are required. C x8 G x1 F x1 H x1 5.8x30mm M x1...
- Page 5 Assembly Instructions Step 1 1. Into Left Side Panel 2 and Right side Panel 3, insert 4 x Male Camlocks B as shown. Connect panels 2 , 3 and 6 together as shown and insert 4 x Female Camlocks C in locations shown.
- Page 6 Assembly Instructions Step 3 1. Slide Back Panel 7 into position shown Step 4 1. Into The underside of Top Panel 1 insert 2 x Male Camlocks B 2. Insert 4 x Dowels A into the Top edge of panels 2 and 3 as shown 3.
- Page 7 Assembly Instructions Step 5 1.Connect your choice of handle either G or N using screw H 2. Connect Catch Plate F using 1 x Screw E 3. Connect Magnetic Catch J using 2 x Screw I 4. Add 4 x Protective feet Step 6 This unit is floor standing but we recommend...
