Iron logic Matrix III EH User Manual

Em-marine / hid proxcard ii 125khz rfid reader with connection via ibutton (1-wire) / wiegand-26 protocols
Hide thumbs
1
2
3
4

Advertisement

Table of Contents

MATRIX III EH
www.ironlogic.me
Matrix III EH
EM-Marine / HID ProxCard II 125KHz RFID reader
with connection via iButton (1-Wire) / Wiegand-26 protocols
User Manual

1. GENERAL INFORMATION

Matrix III EH Reader is used in Access Control Systems (ACS). The reader transmits into the
controller the codes of EM-Marine or HID ProxCard II tokens (cards or key fobs) presented to it, via
iButton (Dallas Touch Memory) or Wiegand-26 protocols.

2. OPERATION

The reader operation without activating external indication control (i.e. staying under internal
indication control):
1. In standby mode, the red LED shines solid.
2. On card approach, the red LED goes off and the green LED flashes once, and a short beep
sounds.
3. While the card remains within working zone, no LED indication is provided.
The external indication control for the LEDs and the buzzer is initiated by connecting corresponding
terminals to common ground. The external indication control for one mode can be used with internal
indication control for another; if, for instance, external indication signal for LEDs is activated, the
LEDs get under external control, while the buzzer remains under internal control.

3. MOUNTING AND CONNECTION

To mount the reader, perform the following sequence:
- Mark and drill the mounting holes per Fig. 2;
- Connect the reader wires according to Table 1;
- Insulate all wire junction points;
- Power up the device (the red LED will come on);
- Test the reader operation by touching it with a token;
- Mount the reader in its desired place and fix it with screws;
- Install the decorative cover and fix it with a screw.
Note 1: Leave 10 cm or more between any two readers.
Note 2: To achieve the specified distance from controller, a UTP cable (e.g. CAT5e compatible)
must be used as follows:
- When using iButton protocol, one wire from the twisted-pair should be connected to GND and
another to DATA0 terminal.
- When using Wiegand 26 protocol, the first twisted pair is connected between GND and DATA0,
and the second one between GND and DATA1, as per Fig. 1.
page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matrix III EH and is the answer not in the manual?

Questions and answers

Related Manuals for Iron logic Matrix III EH

Summary of Contents for Iron logic Matrix III EH

  • Page 1 User Manual 1. GENERAL INFORMATION Matrix III EH Reader is used in Access Control Systems (ACS). The reader transmits into the controller the codes of EM-Marine or HID ProxCard II tokens (cards or key fobs) presented to it, via iButton (Dallas Touch Memory) or Wiegand-26 protocols.
  • Page 2 MATRIX III EH www.ironlogic.me Wiegand DATA0 DATA1 IButton (DS1990A emulation) iButton IButton (One-time transmission) iButton 22 mm 45 mm screw Figure 1. Choosing the transmission protocol Figure 2. Device Dimensions Table 1. Controller connections. Wire Colour Wire Designation +12V Black...
  • Page 3 Humidity: ≤ 98% at 25°C. When operating under non-recommended conditions, device parameters can deviate from specified values. 6. PACKAGE CONTENTS - MATRIX III EH Reader: ...1 - Screw: ......1 - Screws 3.5×40: ....2 - Wall Plugs: ......2 7. LIMITED WARRANTY.
  • Page 4 MATRIX III EH www.ironlogic.me 8. IRONLOGIC CONTACTS Headquarters: RF Enabled ID Limited 34 Ely Place, London, EC1N 6TD, UK E-mail: marketing@rfenabled.com Development and production: AVS LLC 7, Bobruiskaya street, Saint-Petersburg, 195009, Russian Federation E-mail: marketing@rfenabled.com Phone: +78122411853; +78125421185 www.ironlogic.ru Authorized representative in the European Union:...
