Summary of Contents for FAAFTECH FT-TV-1SEG IV
- Page 1 USER MANUAL...
-
Page 3: Table Of Contents
Summary Presentation Package Contents Overview Connections Remote Control Channel Search Channel List Setup Menu Technical Specs Troubleshooting Warranty... -
Page 4: Presentation
Presentation • Congratulations for purchasing the FT-TV-1SEG IV TV receptor, compatible with the Brazilian ISDB-T System. • Please, read this manual carefully before installing your new device. • Keep this manual with you to check the functioning procedures and the security information. -
Page 5: Package Contents
Package contents FT-TV-1SEG IV Device Glass antenna Installation whip IR extensor Remote control User manual... -
Page 6: Overview
Overview 1. Power plug connector, AV output and IR input 2. Antenna plug 3. LED (turns on when the device is plugged in) -
Page 7: Connections
Conexões Antenna Fixate on the front view glass IR Receptor Fixate on a spot easy to use the remote control Plug in to the Post-Key Plug in to the ground connection Video output Plug in to the back-seat screens AV output Plug in to the AV output on the multimedia or on the video interface... -
Page 8: Remote Control
Remote Control Turn the TV on/off Return Access menu Channel forward Channel list and selection Volume down Volume up Channel back Channel search Closed captions... - Page 9 Channel search When you connect the FT-TV-1SEG IV device for the first time, it will require the channel search, in order to memorize your region’s channels. The channel search must be done anytime you relocate to a new city. Just press the screen on the remote control to make the channel search.
- Page 10 Channel List Press the OK button on the remote control to open the channel list. Then, use the CH+ or CH- buttons to flip between channels and press the OK button to choose the channel you wish. Press the button on the remote control to leave the channel list.
-
Page 11: Setup Menu
Setup Menu Press the button on the remote control twice to access the Digital TV Setup menu. Subtitles (Legendas) Use this to turn the subtitles (Closed Captions) on and off. This depends on the channel’s availability. Factory Default (Padrão de Fábrica) Resets all settings to the factory default. -
Page 12: Technical Specs
Technical Specs Technical Specs Technical Specs 7 ~ 18V Operation Tension 200mA Power 2,5W Operation temperature -30 ~ 80°C Storage temperature -40 ~ 85°C Video output CVBS, NTSC Video decoding MPEG-1/2/4, H2.64, WMV9 Video amplitude 1 Vp-p / 50 Ohm Audio decoding MP3, AAC, MPEG4-AAC, MPEG-BSAC Input frequency... - Page 13 Trouble Solving Problem Possible Cause Solution Device’s LED is TV is not being powered Use a multimeter to check turned off the voltage on the power wires (black and red) “NO CHANNEL” No channel has been Make the channel search message memorized on the TV by using the SCAN button...
-
Page 14: Warranty
Warranty FAAFTECH assures their clients a 01 (one) year period against defects in materials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observing the following: 1. FAAFTECH will null the warranty if Faaftech or their authorized technical... - Page 16 TECHNICAL SUPPORT Follow us on social media! 0800 603 2330 or (62) 3241-4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
