Mercedes-Benz E-Class Cabriolet Brief Instructions

E-Class Cabriolet
Brief Instructions
Mercedes-Benz
$ WARNING Make sure that you read the entire Operator's Manual. Otherwise, you may not recognize dangers.
5 DIRECT SELECT lever
6 Multimedia system display
7 Rocker switches for automatic climate
control
8 Direct buttons for main functions of the
multimedia system
Ø Navigation system menu
$ Radio menu
Õ Media menu
% Telephone menu
Vehicle menu
Ø
9 Multimedia system controller
Adjusts the volume
Press: Mute function
Ü Switches the multimedia system on/
off
Seat belt extender
ò Multimedia system main menu
% Back button
P54.26-0902-00
Overview
1 Combination switch for turn signals,
high-beam headlamps and windshield wipers
2 Lever for electrical steering wheel
adjustment and steering wheel heating
3 Lever for cruise control/Active Distance
Assist DISTRONIC
$ WARNING Make sure that you read the entire Operator's Manual. Otherwise, you may not recognize dangers.
Activating/deactivating
1 Switches on with the current speed or calls
up the last set speed
2 Deactivates Active Distance Assist
DISTRONIC
P68.20-5079-00
Operating possibilities for climate control
You can set automatic climate control using:
• The rocker switches on control unit 1 of the
center console
• The climate control menu of the multimedia
system
Air-conditioning function bar 2 shows the most
important settings and the status of automatic
climate control.
Order no. P238 0209 13 Part no. 238 584 75 02 Edition B-2018
2 3 8 5 8 4 7 5 0 2
P68.00-8375-00
a Multimedia system touchpad
b Cabriolet functions
Operates all side windows
Soft top
AIRCAP
c Driving functions
w DYNAMIC SELECT
É Vehicle level
c Active Parking Assist
ECO start/stop function
d ! Electric parking brake
e p Opens or closes the trunk lid
f Door control panel with controls for power
windows, exterior mirror settings and the
override feature in the rear
g Door handle
& Locks the vehicle centrally
% Unlocks the vehicle centrally
Note that your vehicle may not be equipped with all features described.
Combination switch – windshield wiper
functions
1 í
Single wipe
Wipes the windshield using washer
î
fluid
1 $ Windshield wipers off
2 Ä Intermittent wiping, normal
3 Å Intermittent wiping, frequent
4 ° Continuous wiping, slow
5 ¯ Continuous wiping, fast
P54.26-0913-00
Changing the speed
3 Increases the speed or stores the current
speed
4 Decreases the speed or stores the current
speed
5 Increases the specified minimum distance
6 Reduces the specified minimum distance
Note that your vehicle may not be equipped with all features described.
Automatic climate control panel
w Sets the temperature
_ Sets the air distribution
H Sets the air flow, switches automatic
climate control off completely
à Sets climate control to automatic mode
¬ Defrosts the windshield
! Calls up the climate control menu
If you press and hold the t button for
approximately 4 seconds, automatic
climate control will be reset to the basic
settings.
Residual heat with the engine off
¤ Defrosting the rear window
0 Synchronized operation
g Air-recirculation mode
The air in the interior will be recirculated;
the windows may fog up more quickly.
¿ Cooling with air dehumidification
1 Seat functions
Adjusts the seat electrically
c Seat heater
s Seat ventilation
w Adjusts the front-passenger seat
r Memory function and presets
45=
2 Light switch
3 Driver assistance systems
è Active Steering Assist
à Active Lane Keeping Assist
é Deactivates PARKTRONIC
Depending on the equipment, the
button may also be at position c.
Head-up display
4 Multifunction steering wheel control panels
P82.00-3236-00
Overhead control panel
1 Buttons for interior lighting and reading light
2 ï Info call* (mbrace system)
E.g. for questions on vehicle operation
3 G SOS button* (mbrace system)
(Mercedes-Benz emergency call
system)
4 F Breakdown assistance call* (mbrace
system)
* Not available in all countries
Lever on the steering wheel
P54.26-0884-00
Combination switch – lighting functions
1 High-beam headlamps or
Adaptive Highbeam Assist Plus
2 Turn signal, right
3 Headlamp flasher
4 Turn signal, left
Active Distance Assist DISTRONIC
Active Distance Assist DISTRONIC maintains a
constant speed which has been stored.
The lowest speed that can be set is 20 mph
(30 km/h).
You can change the set speed:
1 mph (1 km/h) step: Briefly press the lever
X
up or down.
5 mph (10 km/h) step: Press the lever up or
X
down past the pressure point.
When Active Distance Assist DISTRONIC is
activated, one or two segments in the set speed
range light up in the speedometer.
Using the controller on the DISTRONIC lever, you
can change the specified minimum distance to
the vehicle in front. The specified minimum
distance depends on the currently driven speed.
Climate control menu of the multimedia
system
To call up the climate control menu: Press
X
the t rocker switch on the control panel up
or down.
• SYNC – Changes settings for all climate zones
in the vehicle simultaneously
• A/C – Deactivates the cooling function of
automatic climate control
• Climate Mode – Changes the air flow
• Air Freshener – Sets the intensity of the
perfume atomizer
• Ionization – Freshens the air in the vehicle
interior using ionization
Cockpit – overview
Cockpit – overview
Climate control
