BAK XS20-450TC Operating Manual

OPERATING MANUAL

Air heater Type XS, S, M, L, XL, PN10
Danger to life when opening the air heater, as live components and connections are
exposed. The device must be fully disconnected from the mains before opening. Electric
work shall only be operated by qualified personal (according to TRBS 1203).
Risk of fire and explosion if air heaters are installed and used incorrectly, particularly
near flammable materials and explosive gases. Not suitable for hazardous locations!
The minimal air flow must not be undercut.
Risk of burns! Do not touch heating element pipes and nozzles used when hot. Let the
device cool down. Do not point the hot air jet at persons or animals.
The mains voltage specified on the device's type plate must correspond to the mains
voltage. Air heaters with a fix connection must be connected to a separator ( e.g. mains
switch).
Special connecting conditions
according to IEC/EN 61000-3-11;
Consult your local electricity board if necessary.
Device in protection class I should be earthed using a protective conductor
Device in protection class II
The device must be supervised when in operation. The heat can reach flammable
materials that are out of view.
Protect the device from damp and wet!
Warranty and liability apply from the date of purchase (documented by the invoice/delivery note)
according to the currently valid general terms of business of
refuses any warranty for devices that are not in their original condition.
BAK
No liability can be assumed by
tear of the device (e.g. heating elements).
devices may never be converted and/or modified.
BAK –
reserves the right to deny any responsibility if this is ignored.
BAK
Note:
This operating manual must be available to the installing and operating personnel at all times. Please
read this operating manual carefully before installing and commissioning the device.
Copyright:
This document maybe disclosed to third parties without the express written consent of
type of copying
for incorrect installation and/or use as well as natural wear and
BAK
or recording and
Z = 0.039 + j 0.025 for short time rating (30 min.)
max
Z = 0.026 + j 0.016 for continuous operation
max

WARRANTY AND LIABILITY

BAK AG.
storage in an electronic

SAFETY

BAK AG. Any
form is prohibited.
1
