This guide explains the setup of multiple DX340|HD base stations.

INTERFERENCE AVOIDANCE

Multiple base stations can operate on High or Low parts of the frequency band to prevent interference (heard in a headset as
mechanical sounding voices; voices breaking up while talking; or hearing a "Busy" prompt in the headset when a button is pressed).
For example, if you have two base stations, set one on low band and another on high band, according to the steps below.
1. Turn the base station power on.
The status window will display "8" for a few seconds and
then go blank.
2. Simultaneously press and hold the CLEAR/BAND button
and the REGISTER button. The STATUS window will
display an L, H, A or E (Europe).
3. Quickly, press the CLEAR/BAND button repeatedly to
cycle through parts of the frequency band to stop at the
desired L, H, A or E setting.
Wait until "c" appears on the STATUS display.
NOTE: Base stations are shipped in the "A" (default) position. A "c" will only appear on the STATUS display the first time you are
setting the frequency band, or if you are changing the setting. If you stop at an L, H, A or E that was previously set, an "8" will appear
for a few seconds and the STATUS display will become blank. If you change a base station's existing frequency band setting, you
will have to re-register all beltpacs that were registered to that base station.
HM ELECTRONICS, INC.
2848 Whiptail Loop, Carlsbad, CA 92010 USA
Phone: 1-800-848-4468
Fax: 858-552-0172
Website: www.hme.com
Email: support@hme.com
HD Wireless Headset System
QUICK START GUIDE
L=Low End
DX340 | HD
H=High End
A=All
E=Europe
HME# 400G744
Rev E
3/21/18
