ValsTech LenzO 6/6s Quick Start Manual

LenzO 6/6s
™
Quick Start Manual
Front
Phone on/off/sleep
Color correction flip filters
Hand grip
Camera start/stop/trigger
Removable dome port lens
Unit is sealed with a tight-fit rubber O-ring.
The O-ring is ony accessible when the back
cover is open.
2
2
Phone Preparation
Some screen protectors reduce the contact
sensitivity of the swing arm. If the phone is
not responding, you may want to remove
the screen protector.
Some settings on your phone will need
to be changed before using it with the
LenzO . Make sure the phone is prepped
™
in a dry location.
Back up your iPhone*, and recharge phone
battery to 100%.
Turn off all alarms, calendar events,
and notifications. Set your phone to
AIRPLANE MODE.
Under Settings>Touch ID & Passcode>
iPhone Unlock, set switch to OFF.
Under Settings>Touch ID & Passcode>
Turn Passcode Off. Be sure to re-enable
your password after LenzO use.
™
Under Stterings>General>Auto-Lock, set to
Never.
Back
Rear facing camera/Selfie Mode
Rear camera/
Selfie lens
Secondary Swing Arm
Primary Swing Arm
Home button
Secure seal latch
(push and turn counter clockwise to open)
Phone Preparation
{Continued}
On the Home Screen, move the CAMERA
ICON to the bottom right corner of the
Dock, and the SETTINGS ICON to the
bottom left corner of the Dock.
Set BRIGHTNESS to the maximum and
slide AUTO-BRIGHTNESS to off.
Set the CAMERA FLASH to OFF.
Open the LenzO by pressing and
™
turning the secure seal latch 180° until
the arrow on the latch faces the front
of the housing.
Insert iPhone Home Screen up with phone
case removed. The iPhone camera lens
should line-up with the inside of the housing
lens. Press down on the sides of the phone
to secure it in place with the retaining clips.
1
1
Waterproof Testing
It is important to test the seal of the
LenzO 6/6s before using it with your
™
phone.
Start by closing the housing. Press
the two halves together, and turn the
latch 180°, catching the metal fastener
until the arrow on the latch faces the
back of the housing. When the latch
'clicks', it is ready.
Completely submerge the LenzO
at least 4 inches underwater (in a
bathtub or bucket), for 5 minutes.
Remove, towel dry, open, and inspect
for any leaks or water inside.
If it is dry inside, the LenzO is ready. If
™
there is moisture inside the housing,
remove and lubricate the O-ring (see Step
5: Care/Maintenance), then repeat Step 1.
3
3
Operation
Using the swing arm actuators:
Place thumbs on the swing arm actuators
and gently press down. The internal stylus
tips will press on the phone's screen.
The primary swing arm allows the operator
to swipe the Home Screen, access some of
the phone's settings, and open and control
many of the Camera app's features,
including start, stop,
Using the primary and secondary swing
arms together, the operator has the ability
to zoom in and out with the Camera app,
allowing for the "pinch" or "spread"
gestures necessary for zooming.
in
™
