WALL CABINET INSTALLATION INSTRUCTIONS / OWNER CARE MANUAL
HI‐KAB
Always use two or more people to manipulate & install cabinets. Failure to do so may result in injury.
It is the responsibility of the installer to ensure that wall mounting surfaces and structure are sufficient in strength &
capacity to support cabinet weight and its contents. Failure to observe these conditions may result in injury or death.
HARDWARE SUPPLIED:
TOOLS REQUIRED:
HI‐KAB‐KOMPACT
WARNING: EXCESSIVE WEIGHT HAZARD
WARNING: WALL MOUNTING
Please read these instructions thoroughly prior to installing cabinets. This booklet must
be left with the homeowner once installation is completed
Outdoor installation of this product is not recommended and may void warranty
Gather all packaging materials and recycle whenever possible
Due to reduced clearance of the overhead opening door feature, it is imperative that all wall
surfaces are straight and plumb prior to commencing installation. If wall surface is convex or
concave, interference between cabinet doors may result. Shim all cabinet backs and cabinet
sides as required
If the installation of wall cabinets is performed simultaneously with base cabinets,
it is recommended to install base cabinets prior to mounting wall cabinets
(4x) 2‐1/2" x ¼" Lag Bolts
(2x) ¼"‐20 Phillips Truss Screws
(4x) 5/16" Plastic Hole Plugs (8x for HI‐
KAB+)
Electric Drill with Med Phillips Driver Bit
Med Phillips Head Screwdriver
Ratchet Wrench with 7/16" Socket
5/32" HSS Drill Bit
Small Flat Head Screwdriver
3/32" Hex Key Wrench (For Installation
of optional T‐Handle)
95 Lindsay ave., Dorval, QC Canada H9P 2S6
Toll Free : (855) 4-CONTUR (426-6887)
HI‐KAB+
HI‐KAB+ KOMPACT
(4x) 5/16" Flat Fender Washers
(2x) ¼"‐20 Acorn Nuts
(4x) Pilaster Shelf Clips (HI‐KAB & HI‐KAB+ only)
Spirit Level & Stud Finder
Tape Measure
Lead Pencil
10 mm Hex Key Wrench (Door Stay Adjustment)
Hammer Drill with Masonry Bit (For installation onto
concrete or masonry wall surfaces)
CONTUR CABINET LTD.
www.conturcabinet.com
VENT‐KAB
Advertisement
Table of Contents
Summary of Contents for Contur HI-KAB
- Page 1 CONTUR CABINET LTD. 95 Lindsay ave., Dorval, QC Canada H9P 2S6 Toll Free : (855) 4-CONTUR (426-6887) www.conturcabinet.com WALL CABINET INSTALLATION INSTRUCTIONS / OWNER CARE MANUAL HI‐KAB HI‐KAB‐KOMPACT HI‐KAB+ HI‐KAB+ KOMPACT VENT‐KAB WARNING: EXCESSIVE WEIGHT HAZARD Always use two or more people to manipulate &...
- Page 2 A) UNPACKING CABINET ‐ PRE‐INSTALLATION INSPECTION Caution: Immediately discard polyethylene cabinet bag upon unpacking & removal! Bag is a suffocation hazard and must be kept away from small children and/or pets. 1. Once outer box cover has been removed, remove polystyrene corner protectors from inside top of box. Pull up polyethylene bag away from cabinet and recycle all packaging materials whenever possible. 2. Using two or more people, carefully lift cabinet out of corrugate tray and onto floor. It is recommended to lay the packaging material supplied with the cabinet onto the floor in order to protect the underside of the cabinet during installation. 3. Inspect outer cabinet surfaces for any visible damages. Inspect the hardware bag supplied with this cabinet and verify that all hardware is accounted for. Should there be missing hardware or visible damages to the cabinet, immediately contact your dealer or the factory prior to installation. 4. Do not remove the protective door film at this time. This film will act as a protection against light scratches or scuffs that may inadvertently happen during the installation process. Only once installation is complete can this film be removed. 5. Peel away blue tape from recessed finger‐pull and remove key. B) MOUNTING CABINET TO WOOD STUDDED WALL Caution: Tipping Hazard! Prior to installing and due to the heavy weight of the overhead door, exercise extreme caution when opening. Failure to observe this procedure may result in injury and/or damage to cabinet! 1. This procedure is intended for wall‐mounting a cabinet to a wood‐studded wall. If metal studs are present, do not wall‐ mount cabinet until adequate stud and wall reinforcement is achieved by a skilled and qualified carpenter. Mounting wall must be straight and plumb. If necessary, use wooden shims to adjust the position of the cabinet to the wall. 2. Using a stud finder and lead pencil, mark exact center position of vertical wall studs where cabinet is to be installed. 3.
- Page 3 D) TWINNING OF TWO OR MORE CABINETS 1. All wall cabinets come with pre‐punched twinning holes on opposite sides for easy module alignment & to maintain cabinet stability. It is imperative that all cabinets be joined together as this will combine structural integrity of the cabinets as a set and will eliminate potential sagging and misalignment. 2. For ease of twinning, it is recommended to start the installation with the center cabinet and work in an outwards direction on opposite sides. 3. Position 2 cabinet beside first cabinet and repeat levelling/wall mounting procedure. Verify that both cabinets are level and fasten them together using Phillips truss screws and acorn nuts thru the twinning holes. Tighten firmly. 4. Repeat the same procedure for each additional cabinet. 5. Once twinning is complete, cap the unused twinning holes on each of the end cabinets with the plastic hole plugs. E) TOP‐MOUNTING HI‐KAB+ / HI‐KAB+ KOMPACT MODULE TO DUO‐KAB 1. If DUO‐KAB module is equipped with an escutcheon trim panel, remove five (5) screws and remove panel. 2. With HI‐KAB+ or HI‐KAB+ KOMPACT module resting on the four polystyrene corner packaging protectors, open overhead door and drill one (1) 5/32” hole completely through each bottom corner of cabinet floor. Remove all burrs from holes. (If required, refer to step H for door removal procedure) 3. Mount HI‐KAB+ or HI‐KAB+ KOMPACT module on top of assembled DUO‐KAB. Verify that all four sides of HI‐KAB+ and DUO‐KAB cabinets are flush. Using an electric drill and Phillips driver bit, install four (4) No.8 x 1‐1/4” self‐drilling screws through drilled holes and into top of DUO‐KAB module. Do not over tighten screws so as to avoid distortion of cabinet floor. ...
- Page 4 H) REMOVAL & RE‐MOUNTING OF CABINET DOOR Caution: Tipping Hazard! Prior to installing and due to the heavy weight of the overhead door, exercise extreme caution when opening. Failure to observe this procedure may result in injury and/or damage to cabinet! Caution: Do not attempt to manually work, flex or open the door stay mechanism. This device contains a strong spring that is under extreme load and may cause injury if improperly handled. Door Removal: 1. Unlock and fully open cabinet door. Remove three hinge arm trim caps by carefully prying a small flat head screwdriver between hinge arm and trim cap until cap pops off. 2. Using two or more persons, hold door in fully extended position while another person disconnects the door stay mechanism from the door swivel bracket. Gently pull grey plastic tab backwards until you are able to slide door stay arm away from swivel bracket. Slowly lower door stay to rest. 3. Slightly angle door downwards. Starting with the LH hinge (while another person is holding door), push down on release tab at back of hinge arm to swivel hinge away from hinge plate. Repeat procedure for RH hinge and disconnect center hinge last. 4. Carefully lift door away from cabinet exercising extreme caution not to scratch painted surfaces with exposed hinges. Temporarily store the door face up and away from work area. Do not stack doors on top of each other. Door Re‐Mounting: 5. Verify that all hinges are in a fully‐open position. 6. Slightly angle door downwards. Starting with the center hinge (while another person is holding door), insert hinge onto corresponding hinge plate until release tab clicks into place. Ensure that the guiding pins on the hinge plate align with curved slots of hinge when mounting onto cabinet. If an audible “click” is not heard, verify connection. Repeat procedure for LH & RH Hinges. 7. Swing door stay mechanism arm upwards and into door swivel bracket until it snaps into place. Verify that the door stay arm is fully inserted into the grey plastic tab of the door swivel bracket. 8. Adjust & Align door if necessary. 9. Replace all hinge arm trim caps by aligning mounting tabs over hinge arm openings and snap them into place. ...
- Page 5 K) MOLDED T‐HANDLE ASS’Y INSTALLATION (STANDARD ON HI‐KAB+ MODULE) 1. Open overhead door and locate spare factory‐installed rivet nut on right‐side of door. Using the supplied 8‐32 machine screw and a 3/32” hex key wrench, fasten triangular cable bracket to rivet nut. Tighten firmly. 2. When not in use, T‐handle can be docked onto the door panel. To dock the handle, simply insert nib on back of handle into pre‐punched docking hole. Apply light inward pressure to retain in place. L) LOCKING/UNLOCKING YOUR CABINET DOOR Note: Exercise care and good judgment when storing hazardous chemicals, firearms or other dangerous items inside any lockable cabinet. Unlocking: 1. To unlock your wall cabinet door, hold key by key handle with Contur logo facing downwards. 2. Fully insert flat portion of key into key slot and rotate 90° towards the right. 3. Once cabinet door is unlocked, key can be removed from lock or left in this “parked” position. Locking: 1. To lock your wall cabinet door, hold key by key handle with Contur logo facing downwards. 2. Fully insert flat portion of key into key slot and rotate 90° towards the left. 3. Once cabinet door is locked, key can be removed from lock. 4. With the HI‐KAB+ module, you can conveniently store your unused key inside the T‐handle; located inside the unlocked overhead door.
- Page 6 3M Stainless‐Steel Cleaner & Polish, Part No. 14002 b) ZEP Stainless‐Steel Polish, Part No.0143 Vent‐Kab: 4. To clean washable filter screen, remove four (4) small Phillips screws holding face plate to underside of VENT‐KAB module. On backside of face plate, compress one end of each “Z”–spring to release spring tension on filter screen. Remove filter screen from face plate and gently wash using a soapy warm water mixture. Rinse and dry filter thoroughly overnight. Re‐install filter and re‐attach face plate to VENT‐KAB module in reverse order of above. © 2012 Contur Cabinet Ltd. All rights reserved. ® Registered Trademark/TM of Contur Cabinet Ltd. Specifications shown are subject to change without notice. Printed in Canada Form: WCIE-01 ...
