Summary of Contents for TeleAdapt DeskPoint Pro TA-8050
- Page 1 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 DeskPoint Pro™ User and Installation Manual TA-6950 TA-7950 TA-8050 Keeping Your World Connected™™ 1 ...
-
Page 2: Table Of Contents
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Table of Contents FEATURES......................4 ....................... 6 LED D EFINITIONS ........................7 ONNECTIONS ......................7... - Page 3 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 ........................16 YSTEM OOLS ........................16 Ping Arping ........................17 ........................17 Traceroute ......................18 ETTINGS ...
-
Page 4: Features
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 1. Features The DeskPoint Pro is designed for use in hotel rooms and combines 802.11n, IEEE 802.11g and IEEE 802.11b wireless technology to provide the best wireless performance, enabling client computers to access the resources on the hotel Ethernet network. - Page 5 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 WPA (Wi-Fi Protected Access) - The DeskPoint Pro supports the WPA standard proposed by the Wi-Fi Alliance (Hhttp://www.wi-‐fi.orgH). Both WPA-PSK (Pre-Shared Key) mode and full WPA mode are supported.
-
Page 6: Led Definitions
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Configuration backup - The configuration settings can be backed up to a file via HTTP for later restoring. -
Page 7: Connections
See Figure 3 to the left. TA-8050 provides an RJ45 jack to be used for offering a wired access point for the guest. Pair a TeleAdapt Pull-Through Pro or other Internet AP product for best presentation to the guest. See Figure 4 to the left. -
Page 8: Installing And Configuring Deskpoint Pro
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 2. Installing and Configuring DeskPoint Pro This section offers information about installing your DeskPoint Pro. Before configuring the DeskPoint Pro, you need to know the connection information supplied by your service provider and the field application environment. -
Page 9: Default User Name And Password
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Default User Name and Password The default user name is ‘root’ and the default password is ‘root’. ... -
Page 10: Web Configuration
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 3. Web Configuration NOTE: All management services on the DeskPoint Pro are restricted so they are only accessible via the Hotel LAN port. -
Page 11: Menu Structure
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Menu Structure The left side of the Home page contains a menu for you to carry out commands. Here is a brief description of the hyperlinks on the menu: Summary. -
Page 12: Apply Changes, Reset, Reboot And Continue Commands
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Access Control - Wireless Access Control settings. Status - System monitoring information. Network Status - Shows the packet counters for transmission and reception regarding to wireless and Ethernet networks. -
Page 13: Firmware Tools
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Firmware Tools Firmware management operations for the DeskPoint Pro include firmware upgrade, configuration backup (Load Settings), configuration restore (Save Settings), and configuration reset (Load Factory Fig 6. -
Page 14: Upgrading Firmware By Http Or Tftp
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Upgrading Firmware by HTTP or TFTP To upgrade firmware of the DeskPoint Pro via HTTP: 1. Click Browse and then select a correct firmware .bin file. The firmware file path will be shown in the Firmware file name text box. -
Page 15: Save Settings By Http Or Tftp
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Save Settings by HTTP or TFTP To b ack u p c onfiguration o f t he d evice v ia H TTP o r T FTP: ... -
Page 16: System Tools
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Fig 20. URL box on IE Browser, use https:// for SSL protection. The setting specifies how long the idle time during which the WEB administrator connection is maintained during inactivity. -
Page 17: Arping
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 The function will help you to respond to ping requests from a device on Ethernet or Wide Area Network that are sent to LAN IP . -
Page 18: Time Zone Settings
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 The Internet is a large and complex aggregation of network hardware, connected together by gateways. Traceroute utilizes the IP protocol time to live field and attempts to elicit an ICMP TIME_EXCEEDED response from each gateway along the path to some host. -
Page 19: Periodic Reboot
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Periodic Reboot In this section, you can set a time to order the device to reboot itself automatically. ... -
Page 20: Snmp Trap Table For V1 & V2
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 SNMPv3 primarily added security and remote configuration enhancements to SNMP . There are three modes in the Authentication Level. No Auth, Auth and Auth with priv. Only input the User Name in No Auth mode. -
Page 21: Configuring Tcp/Ip Related Settings
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Up to 5 SNMP (Simple Network Management Protocol) traps can be set in the SNMP Trap Table if SNMP V1/V2 is enabled. -
Page 22: Vlan Tag
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Client Isolation blocks traffic between wired and wireless clients of the DeskPoint Pro. In a hotel environment it is generally desirable to enable this setting to ensure guest privacy. Note however that the DeskPoint Pro will not block traffic between wired and wireless clients connected to different DeskPoint Pro’s, this function must be performed by the network infrastructure. -
Page 23: Configuring Ieee 802.11-Related Settings
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 When VLAN tagging is enabled then the Hotel LAN port will become an 802.1Q trunk. The Web management (or SNMP), Guest LAN and Primary SSID can all be assigned a VLAN tag to allow the network switch to identify and route tagged connection. - Page 24 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 The wireless interface can be enabled or disabled. By default it is enabled. You can choose one Band as follows: ...
-
Page 25: Advanced Setting
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 WMM: The WiFi Multiple Media function is available under 2.4GHz (B), 2.4GHz (G) and 2.4GHz (B+G) band, and is disabled under 2.4GHz (N), 2.4GHz (G+N) and 2.4GHz (B+G+N) band. -
Page 26: Security
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 RTS Threshold: Set the RTS Threshold, value can be written between 0 and 2347 bytes. Beacon Interval: The beacon is a periodic packet the DeskPoint Pro sends out on the air to announce its presence and name (SSID). - Page 27 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Open System - No authentication, no data encryption. Static WEP - WEP (Wired Equivalent Privacy) keys must be manually configured.
- Page 28 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 When WEP is enabled by a security mode, the Key length can be specified to be 64 Bits or 128 Bits.
- Page 29 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Authentication Mode: Select Enterprise (RADIUS) or Personal (Pre-Shared Key) mode. WPA Cipher Suite: here supported AES only. Pre-Shared Key Format: There are two formats for choosing to set the pre-shared key, Passphrase and Hex (64 characters).
- Page 30 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 WPA-Mixed Fig 36. WPA-Mixed settings Authentication Mode: Select Enterprise (RADIUS) or Personal (Pre-Shared Key) mode. WPA Cipher Suite: here supported AES only.
- Page 31 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 mobile users’ access to its wireless LANs. Before being granted access to a wireless LAN supporting IEEE 802.1x, a user has to issue his or her user name and password or digital certificate to the backend RADIUS server by EAPOL (Extensible Authentication Protocol Over LAN).
-
Page 32: Viewing Status
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 5. Viewing Status Network Status Table Fig 38. Wireless/Ethernet Network Status Table On this page, the Ethernet and wireless transport status are shown. -
Page 33: Network Status
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 System events can be logged to the on-board RAM of the Deskpoint Pro (Local log) or Log Server IP Address to a remote Syslog server, respectively. -
Page 34: Technical Support
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 6. Technical Support For North and South American 24/7 Technical Support Toll-Free: 1 877 835 3232 x306 (in US and Canada) Main: 1 775 232 5044 Email: ric.jones@us.teleadapt.com... -
Page 35: Appendix A: Default Settings
TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 Appendix A: Default Settings Setting N ame Default V alue Global User N ame ... - Page 36 TeleAdapt D eskPoint P ro U ser M anual Version 1 2.2011 !""#$%&'()*+',)+-.'/)%%"01".2 36 ...
