Summary of Contents for Newworld FDW600W
- Page 2 ....1 Before you do anything with your new appliance, you should read this manual. This manual contains information about Safety, Operation, Installation and Troubleshooting - all of which will help you get the most from your appliance, and save time and effort when installing.
- Page 3 This appliance must be earthed . In the event Improper connection of this appliance to the of a malfunction or breakdown, grounding will electrical supply is dangerous! reduce the risk of electric shock by providing a path of least resistance of electric current. This Make sure that your supply is suitable for this appliance is fitted with a power lead and plug.
- Page 4 To get the best performance from your dishwasher,read all operating instructions before using it for the first time. 8. ON/OFF button: Switches on the power supply. 1. Pre-rinse light: Illuminates when the pre-rinse cycle is NOTE: This model has a "memory function". Should active.
-
Page 5: Changing The Program
Pre-wash For the heaviest soiled loads, -wash( 0℃ such as pots,pans,casserole Wash (50 ℃) 4/20 g dishes and dishes with food Rinse dried onto them. Rinse (70 ℃) Drying Pre-wash For normally soiled loads, -wash such as pots , plates,glasses Wash (47 ℃) 4/20 g and lightly soiled pans. - Page 6 If your model does not have a water softening facility, you may skip this part. The hardness of the water varies from place to place. If hard water is used in the dishwasher, deposits will form on the dishes and utensils. The appliance is equipped with a special softener that uses a salt specifically designed to eliminate lime and minerals from the water.
- Page 7 Contact your local water board for information on the hardness of your water supply. You should not need to add excess detergent to you dishwasher as it incorporates specially designed water softeners. Always fill the detergent dispenser at the start of each cycle - see the wash cycle table above. A normal wash usually requires one tablespoon of detergent - items which are heavily soiled may require extra.
- Page 8 To open the dispenser, turn the cap to the "open" (left) arrow and lift it out. Pour the rinse aid into the dispenser, being careful not to overfill. Replace the cap by inserting it aligned with "open" arrow and turning it to the closed (right) arrow. The rinse aid is released during the final rinse to prevent water from forming droplets on your dishes that can leave spots and streaks.
- Page 9 Before loading the dishwasher. Scrape off any remaining food - there is no need to rinse dishes before placing them onto the rack. Place objects onto the racks in the following way: 1. Cups, glasses, pats, pans etc should be placed upsaide down. 2.
- Page 10 We recommend that you place large items which are most difficult to clean into the lower rack: pots, pans, lids, serving dishes and bowls, as shown in the figure to the right. It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the top spray arm.
- Page 11 Silverware should be placed into the silverware basket - with the handle end downwards. If the rack has side baskets spoons should be loaded individually into the appropriate slots. Place long items horizontally into the front of the upper rack. 4 4 4 Knife Forks...
- Page 12 A forgotten dish can be added any time before the detergent cup opens. Add forgotten dishes. Please press the start button Do not open the door until the water spray action stops. Close the door and Press the Start button to start washing. Steam may rise out of the dishwasher.
- Page 13 Never run the dishwasher without the filters in place. When cleaning the filters, take care not to damage them. Filters can become damaged quite easily, leading to performance being compromised. To clean the edge around the door, you should use only a soft warm, damp rag. To prevent penetration of water into the door lock and electrical components, do not use a spray cleaner of any kind.
- Page 14 Connect the cold water supply hose to a threaded 3/4(inch) connector and make sure that it is fastened tightly in place. If the water pipes are new or have not been used for an extended period of time, let the water run to make sure that the water is clear and free of impurities.
- Page 15 Dimension: 600x600x850(mm) Capacity: 14 Place setting ater pressure: 0.04-1.0MPa Power supply: See rating label...
- Page 16 Troubleshooting tips. The tips below may save you calling for a service engineer. Always make sure that you read these tips should you encounter any difficulty when using your appliance. Note: A service engineer may charge for his time and labour if he does not find a fault which is electrical or mechanical. Fuse blown, or the Replace fuse or reset circuit breaker.
- Page 17 Combination of soft Use less detergent if you have soft water and select the water and too much shortest cycle to wash the glassware and to get them clean. detergent Tea or coffee stains using a solution of 1/2 cup of bleach and 3 cups warm water to remove the stains by hand.
