Ziton ZPR868 Installation Manual / Instruction Manual

Speci cation
Operating
temperature -10 to +50°C
Storage
temperature -20 to +60°C
Humidity 0% to 95% non-condensing
IP rating IP54
Operating voltage 18 to 22V loop powered
Typical operating
current 26mA loop powered
Max operating
current 77mA loop powered
Operating
frequencies
868 MHz
Output transmitter
power Variable 0-14 dBm
Dimensions 270mm (W) 205mm (H) 75mm (D)
Weight 0.95kg
Data required to conduct tests as speci ed in
EN54-17:2005
Parameter Description
Vmax The maximum line voltage.
Vmin The minimum line voltage.
IC max The maximum rated continuous
current with the switch closed.
IS max The maximum rated switching
current (e.g under short circuit
conditions).
IL max The maximum leakage current
with the switch open (isolated
state).
ZC max The maximum series impedance
with the switch closed
© 2014 EMS Radio Fire & Security Systems Ltd. All rights reserved
Regulatory information
Manufacturer EMS Radio Fire & Security Systems
Ltd. Technology House, Sea Street,
Herne Bay, Kent, CT6 8JZ, United
Kingdom
Year of
manufacture See serial number label inside unit
Certi cation
Certi cation body 0359
CPR certi cate 0359-CPR-0224
Approved to EN54-17
EN54-18
EN54-25

Application

Intended for use in re detection
and re alarm systems in and
around buildings. Indoor use only
European Union
directives
1999/5/EC (R&TTE directive):
Hereby EMS Radio Fire & Security
Systems declares that this device is
in compliance with the essential
requirements and other relevant
provisions of Directive 1999/5/EC.
2002/96/EC (WEEE directive):
Products marked with this symbol
cannot be disposed of as unsorted
municipal waste in the European
Union. For proper recycling, return
this product to your local supplier
Value
upon purchase of equivalent new
22V
equipment, or dispose of it at
16V
designated collection points. For
0.8A
more information see
www.recyclethis.info
3A
Contact information
0.2A
For contact information, see www.utc reandsecurity.com
0.8 Ohm
4 / 4 TSD002 ISS13g 17/02/14 AJM
Radio Loop Module Installation Guide

General

The Ziton Radio Loop Module (RLM) is available under the
following part number:
PART NO VARIANT TYPE
ZPR868 Ziton Radio Loop Module
The address of the unit is set using the onboard 8 way
switches – see supplied table. The installation must
conform to BS5839:Part 1 (or applicable local codes). This
Ziton Radio Loop Module is suitable for indoor use only.

Loop design

The Ziton Radio Loop Module is powered from the loop;
the unit draws a typical current of 26mA. A maximum of
two loop modules can be connected to a loop. The
current drawn from the module should be taken into
consideration when calculating the total load of a loop.

Address setting

It is recommended that the loop address number is
allocated prior to the unit being installed. The address
number is set using the onboard 8 way switch.
Available selections are shown in the Table 1.
© 2014 EMS Radio Fire & Security Systems Ltd. All rights reserved
DIL SWITCH DIL SWITCH
SETTING SETTING
ADDRESS 1...........8 ADDRESS 1..........8
1 10000000 64 00000010
2 01000000 65 10000010
3 11000000 66 01000010
4 00100000 67 11000010
5 10100000 68 00100010
6 01100000 69 10100010
7 11100000 70 01100010
8 00010000 71 11100010
9 10010000 72 00010010
10 01010000 73 10010010
11 11010000 74 01010010
12 00110000 75 11010010
13 10110000 76 00110010
14 01110000 77 10110010
15 11110000 78 01110010
16 00001000 79 11110010
17 10001000 80 00001010
18 01001000 81 10001010
19 11001000 82 01001010
20 00101000 83 11001010
21 10101000 84 00101010
22 01101000 85 10101010
23 11101000 86 01101010
24 00011000 87 11101010
25 10011000 88 00011010
26 01011000 89 10011010
27 11011000 90 01011010
28 00111000 91 11011010
29 10111000 92 00111010
30 01111000 93 10111010
31 11111000 94 01111010
32 00000100 95 11111010
33 10000100 96 00000110
34 01000100 97 10000110
35 11000100 98 01000110
36 00100100 99 11000110
37 10100100 100 00100110
38 01100100 101 10100110
39 11100100 102 01100110
40 00010100 103 11100110
41 10010100 104 00010110
42 01010100 105 10010110
43 11010100 106 01010110
44 00110100 107 11010110
45 10110100 108 00110110
46 01110100 109 10110110
47 11110100 110 01110110
48 00001100 111 11110110
49 10001100 112 00001110
50 01001100 113 10001110
51 11001100 114 01001110
52 00101100 115 11001110
53 10101100 116 00101110
54 01101100 117 10101110
55 11101100 118 01101110
56 00011100 119 11101110
57 10011100 120 00011110
58 01011100 121 10011110
59 11011100 122 01011110
60 00111100 123 11011110
61 10111100 124 00111110
62 01111100 125 10111110
63 11111100 126 01111110
127 11111110
1 / 4
TSD002 ISS13g 17/02/14 AJM
Table 1
