Bluetooth Speaker

ES-63012BT

SHENZHEN AOB ELECTRONICS CO.,LTD

PLEASE READ ALL INSTRUCTIONS CAREFULLY

RETAIN FOR FUTURE USE

Package Contents

*Bluetooth Speaker

*Adapter

*3.5mm audio connection cable

*Instruction manual

1-Compatible with Bluetooth devices & connects via 3.5mm audio jack

2-Heavy bass effect, creates a perfect sound environment .

3-Rechageable built-in battery

1-Speaker

2-On/Off power switch

3-LED Indicator

4-DC-IN

5-AUX IN

6-Bass volume up and down

7-Volume up and down

INSTUCTIONS FOR USE

For best results, fully charge for unit before first use (8 hours should be better).

1-Connect the Adapter to the charging port located at the back of the speaker and

insert the other end into the power source.

2-The LED at the back turns red when the battery is being charged. Once it is fully

charged the Red LED will turn off. It will take about 6 hours to fully charge the

battery.

Table of Contents

Do you have a question about the ES-63012BT and is the answer not in the manual?

Page 1 Bluetooth Speaker ES-63012BT SHENZHEN AOB ELECTRONICS CO.,LTD PLEASE READ ALL INSTRUCTIONS CAREFULLY & RETAIN FOR FUTURE USE Package Contents *Bluetooth Speaker *Adapter *3.5mm audio connection cable *Instruction manual Features 1-Compatible with Bluetooth devices & connects via 3.5mm audio jack 2-Heavy bass effect, creates a perfect sound environment .
Page 2 *Turn On/Off the Bluetooth Speaker *Slide the On/off button at the back of speaker. Turn the speaker to Bluetooth pairing mode. 1-Slide the On /Off button at the back of speaker 2-The Blue LED blinks. This indicates that it is in pairing mode. (Noted: If you have paired to the speaker before, then the speaker will pair automatically with the last device it connected) Pairing your device with Bluetooth Speaker...
Page 3 Specification Speaker size: 4inch * 2 Speaker power: 10W Power output: Rms 5.5w*2 Built-in lithium battery : 2000mAh / 7.4V Power supply：DC 9V Frequency response: 80HZ-20KHZ Resistance: 4Ω Charging time: About 8 hours Unit size: 45cm*45cm*45cm *Bluetooth version: V2.0+EDR *Spare parts : AUX cable, DC 9V adapter FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
