DX-300 – DIVER HELD MAGNETOMETER

UNDERSEA DETECTION EQUIPMENT

DIVER HELD

MAGNETOMETER

Operating Instructions

replicated in whole or part without the prior express permission of Aquascan International Ltd.

Issue date

24th June 2014

AQUASCAN INTERNATIONAL LTD.

AQUASCAN HOUSE

HILL STREET

NEWPORT.

SOUTH WALES. UK

NP20 1LZ

Tel: +44 1633 841117

Fax: +44 1633 254829

Email:

Website :

DX-300

.....

User Manual

info@aquascan.co.uk

www.aquascan.co.uk

Table of Contents

Need help?

Do you have a question about the DX-300 and is the answer not in the manual?

Questions and answers

Summary of Contents for AQUASCAN INTERNATIONAL DX-300

Page 1 ..Operating Instructions ..This manual is copyright © 2014 Aquascan Int. Ltd, all rights reserved. This document must not be replicated in whole or part without the prior express permission of Aquascan International Ltd. Issue date 24th June 2014...
Page 2: Table Of Contents
DX-300 – DIVER HELD MAGNETOMETER User Manual Page/Contents Front Page of Contents Introduction Applications Example of appropriate use of the DX-300 General comments The DX-300 Equipment Initial Testing of your DX-300 Charging the batteries Underwater Operation Care and Maintenance Battery Care & Checking Battery Performance/Status...
Page 3: Introduction
The DX-300 is taken to the bottom by the diver, after the unit is switched on and set to Hi...
Page 4: General Comments
General comments The DX-300 is NOT a metal detector. It detects localised disturbances in the earth’s magnetic field that are caused by the presence of ferrous material. The user should note that other things can cause magnetic disturbances that will affect the DX-300 operation.
Page 5: Initial Testing Of Your Dx-300
This section explains the basic functionality of the DX-300 and how to use the controls. It is much easier to learn to operate the unit without the challenges of limited visibility, restrictive dive equipment, currents, etc.
Page 6 3. To prepare the DX-300 for use, plug the connector on the Sensor Probe into the SENSOR socket and screw down the retaining collar. This should be good finger tightness only.
Page 7 Test the operation of the DX-300 by walking slowly towards the target with the Sensor Probe pointed down at about 45 degrees rather than vertical to increase the lateral sensitivity.
Page 8: Underwater Operation
DX-300 – DIVER HELD MAGNETOMETER User Manual 8. As you get closer and closer to the target, the DX-300 will begin to have constant audio output pitch, so you will need to lower the sensitivity to be able to actually pinpoint the target.
Page 9: Care And Maintenance
AUDIO control knob. Care and Maintenance Proper care of your Aquascan DX-300 will be repaid by a long and trouble free life and attention should be given to the following points: - 1. After use, and before removing plugs, make sure that the unit is switched off, and wash down with clean fresh water.
Page 10: Battery Care & Checking Battery Performance/Status
3. Recharge the batteries if the total hours used is approaching 10. 4. Never leave your DX-300 lying in the hot sun, as this could raise the internal temperature to the point where it may distort the case and harm the electronics.
Page 11: Troubleshooting Guide
No Response from DX-300 Module Check the following:- Check that the battery has been charged – If not, place DX-300 on charge and then re-test. Note. As the voltage drops below a certain point, erratic behaviour will result. Further decrease in voltage will result in total lack of functionality.
Page 12 DX-300 – DIVER HELD MAGNETOMETER User Manual Symptom: Erratic Performance from DX-300 Module First check as above. Check that the contacts of the bulkhead connectors are clean. Check that the connectors of the Sensor Probe and Bonephone are clean. If necessary reduce the contact resistance by slightly prising the gap in the male contacts, this will increase the firmness of the connector on insertion.
Page 13: Dx-300 Specifications
DX-300 – DIVER HELD MAGNETOMETER User Manual DX-300 – SPECIFICATIONS MATERIALS & DIMENSIONS: INSTRUMENT CASE Housing material ......Machined uPVC Housing Dia ..........100mm Overall length ..........187mm MAGNETOMETER PROBE Probe housing..........GRP Probe Dia ............. 25mm Probe Length ..........750mm CABLE Construction ......
Page 14: Dx-300 Accessories
AQ.4.030 DX-300 Land Headphones – Rugged headphones optional accessory for use above water; enabling The DX-300 to be utilised as a powerful ferrous metal land detector. The Headphones feature an adjustable volume control and a comfortable fit for the user.
Page 15 DX-300 – DIVER HELD MAGNETOMETER User Manual AQ.4.010 Battery Charger – Switched mode unit with 100v to 250v AC 50/60HZ input voltage range this unit is used to recharge the internal battery pack of the DX-300 Control Module. The charger can be...
Page 16: Dx-300 Optional Accessories
DX-300 – DIVER HELD MAGNETOMETER User Manual DX-300 – OPTIONAL ACCESSORIES Optional DX-300 Armsaver – probe extended Optional DX-300 Armsaver – probe retracted DX-300 Control Unit mounted in optional Armsaver Close up of DX-300 Armsaver Probe connection...
Page 17: Dx-300 Professional Kit
DX-300 – DIVER HELD MAGNETOMETER User Manual DX-300 – PROFESSIONAL KIT DX-300 Professional Kit - Case closed DX-300 Professional Kit Includes: Transit/Storage case for DX-300. Control Unit, Sensor Probe, D Ring, Waist Belt, Charger, Bonephone, Underwater Headphones, and Armsaver kit.
Page 18: Manufacturer Contact Information
DX-300 – DIVER HELD MAGNETOMETER User Manual Manufacturer Contact Information If you should need to contact Aquascan International Limited for advice on your purchase, to order further equipment or to arrange a repair, please use the following contact information: -...
Page 19: Ec Declaration Of Conformity
DX-300 – DIVER HELD MAGNETOMETER User Manual Aquascan International Ltd. EC Declaration of Conformity We hereby declare that the following equipment complies with the essential requirements at the Electronic Compatibility Directive (89/336, 91/26 3 and 92/31). This equipment should not be modified, without our approval, as this declaration will lose its authority.
