Angelbird WINGS PX1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER MANUAL
WINGS PX1
W I N G S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WINGS PX1 and is the answer not in the manual?

Questions and answers

Summary of Contents for Angelbird WINGS PX1

  • Page 1 USER MANUAL WINGS PX1 W I N G S...

  • Page 2: Table Of Contents

    2.2 System Requirements 3. SUPPORT 4. HANDLING 5. INSTALLATION 5.1 Installing the M.2 SSD on the Wings PX1 5.2 Installing the Wings PX1 into a computer 5.2.1 Installion into a Mac Pro 5.2.2 Installion into a PC 6. TECHNICAL SPECIFICATIONS 6.1 General Specifications...

  • Page 3: Introduction

    INTRODUCTION 1.1 Introduction Welcome to the manual for your Wings PX1. The Wings PX1 is M.2 SSD to PCIe adapter. You can attach a single M.2 AHCI SSD or M.2 NVMe SSD to the adapter and built it into a PCIe slot of a computer.

  • Page 4: Requirements

    2.1 SSD Requirements For a list of tested compatible M.2 SSDs, see the SSD Compatibility list on page 8. The following two interface types of M.2 SSDs are supported by the Wings PX1. • M.2 NVMe SSD • M.2 AHCI SSD The following M.2 form factors are supported by the Wings PX1.

  • Page 5: Support

    4. Handling Before removing the Wings PX1 from its packaging, please be conscious of static electricity as it could damage the device. For example, touch a metal object to discharge your static electricity. Remember to disconnect power and turn off the devices you are handling.

  • Page 6: Installation

    INSTALLATION Two steps are required to start using the Wings PX1. 5.1 Installation of the M.2 SSD on the card. 5.2 Installing the card into a computer. The next sections guide you through these steps. 5.1 Installing the M.2 SSD on the Wings PX1 Before you can install your Wings PX1 into a computer, you first need to install a M.2 SSD on the card.
  • Page 7 INSTALLATION For some SSDs it is possible to use an extra thermal pad for even more heat dissipation. In case the SSD has no components its bottom side, you can place the thermal pad within the alignment marks marked with “2280” (fig.

  • Page 8: Installing The Wings Px1 Into A Computer

    For instructions on how to install in a PC, please see the section installation in a PC. IMPORTANT Before installing the Wings PX1, please make sure that the computer is turned off and the power plug is disconnected. W I N G S...

  • Page 9: V. Remove The Pcie Acess Cover (1) And Then The Pcie Cover Bracket (2) For The Chosen Slot (Fig

    5.2.1 Installation into a Mac Pro Locate the cover release lever on the back of the case, and pull it. This will release the cover plate lock (fig. 7) Remove the right-hand-side cover plate (fig. 8) (fig. 7) (fig. 8) Remove the PCIe access cover III.
  • Page 10 Installation into a Mac Pro Gently insert the Wings PX1 into the selected slot (fig. 10) NOTE Do not force insertion as it may cause damage to the Wings PX1 and the computer. (fig. 10) VII. Put back the PCIe access cover (fig. 11) (fig.

  • Page 11: Installion Into A Pc

    There are many different types of computers. If you are unsure about any of the steps, consult the manual of your computer. IMPORTANT Before installing the Wings PX1, please make sure that the computer is turned off and the power plug is disconnected. Remove the access cover so you can access the PCIe slots (fig.

  • Page 12: Do Not Force Insertion As It May Cause Damage To The Wings Px1 And The Computer

    Place and fasten a PCIe bracket screw to securely fix the Wings PX1 card to the chassis (fig. 17) (fig. 17) IMPORTANT Do not force insertion as it may cause damage to the Wings PX1 and the computer. Replace the cover plate. W I N G S...

  • Page 13: Technical Specifications

    To receive the full limited manufacturer warranty, it is required to register and activate the product on the Angelbird Personal Service Portal within thirty (30) days after purchase. The required activation code is provided in the product packaging. When the product is not registered within this period, the legal guarantee period is in effect.

  • Page 14: Ssd Compatiblity List

    OS X are registered trademarks of Apple Inc. in the U.S. and other countries. ® ® ® Wings is a trademark of Angelbird Technologies GmbH. ™ All other marks are property of their respective owners. W I N G S...
