Axis XT1408A Installation Manual

8" (200mm) COMPACT UPRIGHT
AMPLIFIED SUBWOOFER

SPECIFICATIONS

GENERAL
- Cabinet:
- Mounting:
- Mounting Position:
- Weight:
- Dimensions:

POWER AMPLIFIER

- Input:
- RMS Power Output:
- Maximum Output:
- Sensitivity:
- Control:
- Control Features:
- Power Source:
- Current:
- Grounding:
INCLUDED
- Remote controller:
- Installation hardware
XT1408A
High density compound resin
Metal brackets (pair)
Behind seats, on panels, cargo areas
Approx 3.5 kg (including accessories)
250 (W) x 265 (H) x 118 (D) mm
High (speaker wires) or low level (RCA)
125 watts @ 14.4V 80Hz 2
250 watts
102dB
Wired remote controller
Frequency (50 ~ 125 Hz) gain and phase
14.4V DC (10.8 ~ 15.6V)
8A Max
Negative
Adjusts volume, gain, frequency & phase
INSTALLATION MANUAL

FEATURES

• 200mm (8-Inch)
• Integrated Low Profile Subwoofer with Power Amplifier
• Upright Design for Utilities & RV's
• Simple Installation Behind Seats, On Panels and Cargo Area
• Easy Connection from High Level Speaker Wires or
Low Level RCA
• Full Featured Wired Controller
INTEGRATED SUBWOOFER
- Speaker:
- Cone Diameter:
- Max Power:
- Voice Coil:
- Magnet:
- Frequency:
High compliance, rolled edge
200mm (8-inch)
250 Watts
Heat Resistant Ø35mm
16 oz (440g) Strontium
37 - 200Hz
2
YEAR
WARRANTY
