Setting Up The Camera And Monitor - eufy Security SpaceView User Manual

Camera Features:
1
2
3
4
Standard camera lens
1
Microphone
2
Power LED Status indicator
3

Setting Up the Camera and Monitor

Monitor Installation
Fully charge the monitor before use. To charge:
Connect the baby monitor to the monitor adapter with the
Micro USB cable, and then connect the adapter to a power
outlet. Connect the other end of the baby monitor's Micro
USB power cable to the Micro USB port in the monitor to
03
5
6
Speaker
4
Micro USB port
5
Pairing button
6
charge it. Press and hold the power button for 2 seconds to
turn the baby monitor on.
Camera Installation
Connect the baby camera's Micro USB power cable to the
camera adapter (5V 2A), and then connect the adapter to
a power outlet. Finally, connect the other end of the baby
camera's micro USB power cable to the micro USB port in the
camera.
Camera Placement (on the Wall Mount)
1. Use the monitor to test the viewing angle from
your desired mounting spot.
2. Mark the screw holes with a pencil.
3. Drill 1/5" holes into the wall and then insert the
anchors into the holes.
4. Insert the screws through the mounting holes of
the base and screw into the anchors.
5. Place the camera on the base.
04
