- Page 1 USER GUIDE Adult assembly required Read User Guide before assembling Please keep this guide for further reference Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk...
-
Page 2: Your Warranty
Your Warranty Silver Level Warranty Ranges covered by this warranty level: Frame – 10 years – structural failure due to rust XR Series 300 & 360 Springs – 10 years structural failure due to rust 12’x’8 Rectangular Bed – 5 years – structural failure due to rot King 110 Frame Pad –... -
Page 3: Before You Start
The XR360 trampoline is designed to stand on a lawn or other soft surfaces such as artificial grass and bark. If you are positioning your trampoline on an abrasive surface such as concrete or gravel, the underside of the leg bases will deteriorate quickly. - Page 4 Safe Bouncing Guide Standing Bounce Use the basic “feet to feet” standing bounce to warm up and get the feel of the trampoline. Try to keep the body straight. Your legs should be slightly apart when landing on the bed and together in the air with toes pointed.
- Page 5 Safe Bouncing Guide Pike Jump Start as if doing a standing bounce. At the top of your bounce, bend your body at the hips by raising your legs whilst keeping them straight and together. Arrive at the horizontal position and briefly touch your shins.
- Page 6 XR360 Parts List 2 x End Rails 4x Leg Bases 1 x polymesh bed 2 x Side Rails 8 x Leg Extensions 88 x 216§mm Springs 4 x Frame 4 x Corner Pieces Connectors 10 x 165mm Toggle Loops Frame Pads x1 section...
-
Page 7: Exploded Diagram
Exploded Diagram Frame Pads Polymesh End Rail Frame Connectors Corner Peice Leg Bases Extension Side Rail Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk... -
Page 8: Assembling The Frame
Start by laying the frame parts out on a flat surface. Please note that the side rails of the XR360 bow outwards (part A). Please take this into consideration when positioning the parts on the floor. Please also note the positioning of parts C &... - Page 9 STEP Now fit each leg assembly to the top rail section by slotting it onto a stub on the end rail (part B) and a stub on the side rail (part A). Note that each leg assembly will fit diagonally across each corner of the frame with one leg extension fitting to an end rail stub and the other to a side rail...
- Page 10 STEP Using the diagram provided for guidance, use the springs to Fit the first 20 springs in fit the bed to the side rails and end rails. Fit the corner springs the order shown below. first, and then side rails. STEP With the bed now fitting loosely to the frame, proceed to fill in the gaps around the frame ensuring that you work symmetrically so that the tension is distributed evenly around the bed.
- Page 11 Fitting the Frame Pads STEP Unfold the pads in half so that the underside is face-up Eyelets on underside with the brass eyelets showing of Frame Pad STEP Toggle Loop Start threading the black elasticated end of the toggle loops through the eyelets in the frame pads.
- Page 12 STEP Proceed to fix the frame pads in to place by looping the toggle loops around the frame and then secure by pulling the black toggle through the elastic. Do this for all 20 toggle loops. Once you have completed wrapping the toggles, make sure you pull the skirt of the frame pad down around the edge of the frame.
- Page 13 STEP STEP Before you start, position the following parts Start by removing the foam from the bottom next to each of the 8 vertical trampoline legs at enclosure poles. each corner: Next, proceed to fit each bottom enclosure 1 x bottom pole with foam pole to the vertical trampoline leg by using the clamps provided.
- Page 14 Fitting the Safety Net Top Pole Enclosure STEP Lay the enclosure net on top of the trampoline ensuring that Elasticated bungee you align the zip so that it is with Q hooks positioned between two enclosure poles on the short end of the frame.
- Page 15 Trampoline Care and Maintenance General Useful Information Your Super Tramp trampoline has been designed to A stretched or dead spring can be identified live outdoors all year round and will generally where there is visible light through the coils of require very little maintenance.
- Page 16 Thank you for purchasing a Super Tramp Trampoline We hope you found this guide helpful. Visit our website for our full range of trampolines, spare parts and accessories www.supertramp.co.uk Follow Us On Social Media! @supertrampuk @supertramptrampolines Tel: +44 (0)1884 675801 | www.supertramp.co.uk | sales@jetsports.co.uk...
