RFL Electronics IMUX 2000 Instruction Manual

8-port t1/e1 dacs with redundant capability
Hide thumbs Also See for IMUX 2000:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
The information in this manual is proprietary and confidential to RFL Electronics Inc.
Any reproduction or distribution of this manual, in whole or part, is expressly
prohibited, unless written permission is given by RFL Electronics Inc.
This manual has been compiled and checked for accuracy. The information in this
manual does not constitute a warranty of performance. RFL Electronics Inc. reserves
the right to revise this manual and make changes to its contents from time to time. We
assume no liability for losses incurred as a result of out-of-date or incorrect information
contained in this manual.
Publication Number MC 2000DACS8P
Printed In U.S.A.
Revised April 18, 2007
IMUX 2000 DACS8P
April 18, 2007
B e c a u s e R F L ™ a n d H u b b e l l ® h a v e a p o l i c y o f c o n t i n u o u s p r o d u c t i mp r o v e me n t ,
RFL Electronics Inc.
INSTRUCTION MANUAL
IMUX 2000
8-Port T1/E1 DACS
WITH
REDUNDANT CAPABILITY
NOTICE
we r e s e r v e t h e r i g h t t o c h a n g e d e s i g n s a n d s p e c i fi c a t i o n s wi t h o u t n o t i c e .
i
© Copyright 2007 by
RFL Electronics Inc.
RFL Electronics Inc.
(973) 334-3100
