Gorke Electronic OBI 3SH User Manual

TECHNICAL PARAMETERS

Frequency
Transmission
Number of keys
Type of receiving module
Sensitivity
Power
Memory capacity
Event Log
Acoustic signaling
Repeating signal
Dimension (mm)
Color
Compatibility
Operating range (m):
Pager has acoustic signaling of low battery condition and their transmitters it conects.
Sold complete with antenna and belt clip.
* Operating range
150 m Remotes type PUK
300 m The hermetic PNH 201
500 m Panic remote PUK 303
800 m retransmiter RTS 100, remote controls high-range RNB and stationary transmitters type NRP
The reported ranges refer to the open space (without any obstacles, when the pager and the transmitter can "see" each
other). If between pager and transmitter are obstacles, there should be a reduction in the operating range respectively
for: wood and plaster of 5-20%, 20-40% brick, reinforced concrete by 40 - 80%. With the many obstacles we advise to
use retransmitters or stronger remote controls. For metallic obstacles applying radio systems is not recommended.
1. ON - Turn on/off the device.
C
start – hold
•
C
stop – hold
•
Standby PAGER is indicated by the flashing LED.
After switching PAGER performs a power supply test, the completion of which is indicated by switching on of all
segment display. Procedures PROGRAM, EDIT and CLEAR must be performed after completion of the test power.

2. WORKING STATE.

PAGER receive the signal from the programmed transmitter causes: switching sound signaling,
Display programmed description of the transmitter (3.4) and briefly displays the number of memory cells
PAGER under which the transmitter has been programmed. The signaling continues for 20s, then is recalled.
key - Viewing alarms
• /
C
key - Clearing alarms
•
During the reset alarms first pressing
and memory PAGER.
USER MANUAL
device type OBI 3SH PAGER
rolling code KeeLoq ® Microchip Technology)
1xbatery 9V/ 6F22 (standard) or nickel metal hydride
any GE sender (except NRP 102K), retransmitter
from 150 to 800 depending on the transmiter*
until the string ON appears.
until the string OFF appears.
C
cancels the audible signal, the second pressing deletes the record on
433,92 MHz
superheterodyne
-115 dBm
rechargeable NiMH 8.4V / 170mAh
500 transmitters
the duration of signaling: 20s
every 30s until cleared
65*100*24
type RTS 100
4
500
black
the
display
