Summary of Contents for Amtune AM-C303
-
Page 1: User Manual
Amtune HD Video Converter Series HD VIDEO CONVERTER USER MANUAL AM-C303 HDMI to YPbPr+L/R Audio Converter... - Page 2 Amtune HD Video Converter Series I. Introduction HDMI to YPbPr signal converter which will convert HDMI signal to YPbPr video signal and audio signal. It offers solutions for digital entertainment center, HDTV retail and show site, HDTV, STB, DVD and Projector factory, noise space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
- Page 3 Amtune HD Video Converter Series III. Specification Signal Inputs/Output Input Video Signal 0.5-1.0 volts p-p Input DDC Signal 5 volts p-p (TTL) Input HDMI / DVI TV: 480i/576i/480p/576p/720p/1080i/1080p PC: 800x600p/1024x768p/1152x864p/1280x720p/ 1280x768p/1280x800p/1280x960p/1280x1024p/ 1360x768p/1366x768p/1440x900p/1440x1050p/ 1600x900p/1600x1050p/1600x1200p/1680x1050p/ 1920x1080p Output YPBPR / Resolution 480i / 576i / 480p / 576p / 720p / 1080i / 1080p...
- Page 4 Amtune HD Video Converter Series IV. Functions and Operation Control Function Interface ① HDMI input interface ② DC power input interface ③ Button 1 = Choose the zoom out level ④ Button 2 = Choose the output video resolution ⑤...
- Page 5 Amtune HD Video Converter Series V. Product Connection Diagram Before installation, please make sure all devices you wish to connect have been turned off. 1. Connect the HDMI to this Converter. 2. Connect the YPbPr video and R/L audio output from this product to the TV which has YPbPr input.
