Summary of Contents for TelcoBridges TM-1000
- Page 1 TM-1000 Installation Guide for Toolpack Monitoring Document number 9000-00015-1A Mai 2016...
- Page 2 OC3/STM-1, TB-8-E1/T1/J1, TB-IVR Mezzanine, TB-Multi-Blade, TB-Multi-Blade Mezzanine, TB-N+1-15 Solution, TB-N+1-3 Solution, TB-StreamServer, TB-Video, TB-VoIP Mezzanine, TM-1000 Network Probe are trademarks of TelcoBridges Inc. All rights reserved 2007. All other trademarks are property of their owners. Information subject to change without notice.
-
Page 3: Preface
Obtaining Support Email Technical Support Remote technical support by email is available to all TelcoBridges customers 7 days a week, 24 hours a day, and enquiries shall be responded to no later than 36 hours after reception. Please send technical support requests by email to: support@telcobridges.com To accelerate the service, please send your request for technical support with the following information: 1. - Page 4 Software version Comments about the TelcoBridges Documentation TelcoBridges Welcomes Your Comments TelcoBridges is interested in improving its documentation and welcomes your comments and suggestions. You can email your comments to TelcoBridges at: support@telcobridges.com Please include the part number or name of your document in the subject line of your email.
-
Page 5: Table Of Contents
Patch panel rear view ............................20 3.3. Patch panel trunk impedance selector switch ...................... 21 3.4. Patch Panel Selector Switch Fit with TM-1000 Cable-1 ..................22 3.5. Patch panel selector switch fit with TM-1000 cable-2 ..................22 3.6. Patch panel selector switch fit with TM-1000 cable-3 ..................23 3.7. - Page 6 Figure 11 TM-1000 rear view DC Power supply option and ground post ............... 14 Figure 12 TM-1000 rear view AC Power supply option, On/Off switch and ground post ..........14 Figure 13 TM-1000 rear view Reset and auxiliary feature ....................15 Figure 14 TM-1000 rear view RS-232 Link ........................
-
Page 7: System Requirements
Two Gigabit switches (8 ports minimum) for control redundancy • Four Ethernet cables • One power source, either 110-220V AC, 4 AMP for TM-1000 option AC or 48V DC, 9 AMP for TM- • 1000 option DC Up to 64 E1/T1/J1 source for monitoring full-duplex •... -
Page 8: Application Server Requirements
Windows 2000 Professional/Server with Service Pack 3 or later, or Windows XP with Service Pack 2 or • later. The TM-1000 software package has not been tested on any other version of Windows. 1.2.2. Recommended Linux System Requirements Intel or AMD-based system, 3Ghz or more with 1GB of memory •... -
Page 9: Hardware Equipment
Wear an ESD-preventive wrist strap, ensuring that it makes good skin contact. Connect the clip to an unpainted surface of the TM-1000 to channel unwanted ESD voltages safely to ground. To guard against ESD damage and shocks, the wrist strap and cord must operate effectively. -
Page 10: Tm-1000 Environmental Specifications
Access to ports is sufficient for unrestricted cabling • AC power cord can reach from the AC power outlet to the connector on the TM-1000. The power outlet • must be accessible at all times because it serves as the main method to disconnect power from the TM-... -
Page 11: Tm-1000 Right Side View
Figure 4 TM-1000 right side view 2.4. TM-1000 left side view Cooling fans Figure 5 TM-1000 left side view with three cooling fans 2.5. TM-1000 rack-mounting brackets and screws Figure 6 TM-1000 left and right side bracket kit Copyright © 2003-2016 by TelcoBridges... -
Page 12: Tm-1000 With Left Side Bracket Installed
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 2.5.1. TM-1000 with left side bracket installed Figure 7 TM-1000 left side right angle 2.5.2. TM-1000 with right side bracket installed Figure 8 TM-1000 right side right angle Page 12 of 32 Copyright © 2003-2016 by TelcoBridges... -
Page 13: Tm-1000 Led Description
9000-00015-1A CONFIDENTIAL TM-1000 Installation Guide for Toolpack 2.6. TM-1000 LED Description Figure 9 TM-1000 Front View LED description Item Color Description Item Color Description None No power None Not finished restarting the TM- 1000 Power fault Ethernet port disconnected Green... -
Page 14: Tm-1000 Dc Power Supply Option
Figure 12 TM-1000 rear view AC Power supply option, On/Off switch and ground post Power input from 100 to 240V AC, 47 to 63 Hz with 4 Amp maximum load. This is an auto detect AC power input. -
Page 15: Tm-1000 Reset, Auxiliary 1 And 2 Description
If you hold on the reset button for at least five seconds, the TM-1000 will shut down. If you hold on the reset button for at least five seconds after a shut down, the TM-1000 will restart. Aux-1 and Aux-2 RJ-45 connectors are used for optional features. These features are not implemented yet. Do •... -
Page 16: Tm-1000 Serial Port Rs-232
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 2.10. TM-1000 Serial Port RS-232 Figure 14 TM-1000 rear view RS-232 Link Figure 15 TM-1000 RS-232 Pin Out Pin number Description Not connected Receive signal (Rx) Transmit signal (Tx) Not connected Ground Not connected... -
Page 17: Tm-1000 Ethernet 1 And 2
9000-00015-1A CONFIDENTIAL TM-1000 Installation Guide for Toolpack 2.11. TM-1000 Ethernet 1 and 2 Figure 16 TM-1000 rear view Ethernet 10/100/1G ports Item Led color Description Ethernet port connected 100M Yellow Ethernet port connected 1G Ethernet port disconnected Solid Green Ethernet port connected... -
Page 18: Tm-1000 E1/T1/J1 Input Cable Connectors
2.13. TM-1000 E1/T1/J1 Input Cable Connectors Figure 17 TM-1000 rear view SCSI-3 input connection 2.14. Patch panel SCSI-3 connector Plug only with Cable-2 or Cable-4 of the TM-1000 Plug only with Cable-1 or Cable-3 of the TM-1000 Figure 18 Patch panel SCSI-3 connector The lower SCSI-3 connector is always connected with patch panel number 1 to 16. -
Page 19: Table 8 Tm-1000 Scsi-3 Trunk Cable Input
RJ45 Pin 4-5 input Cable-1 Trunk 1-16 Trunk 65-80 Cable-2 Trunk 17-32 Trunk 81-96 Cable-3 Trunk 33-48 Trunk 97-112 Cable-4 Trunk 49-64 Trunk 113-128 Table 8 TM-1000 SCSI-3 trunk cable input Copyright © 2003-2016 by TelcoBridges Page 19 of 32... -
Page 20: Patch Panel With 32 X Rj-45
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 3. Patch panel with 32 x RJ-45 This patch panel supports 64 trunk inputs (32 full-duplex trunks). 3.1. Patch panel front view Figure 19 Patch panel front view 3.2. Patch panel rear view... -
Page 21: Patch Panel Trunk Impedance Selector Switch
9000-00015-1A CONFIDENTIAL TM-1000 Installation Guide for Toolpack Patch panel trunk impedance all selector switch • Figure 21 Patch panel impedance selector switch 3.3. Patch panel trunk impedance selector switch Switch 3 and 4 Switch 1 and 2 Figure 22 Patch panel impedance selector switch Always set the impedance switch as a pair 1-2 and 3-4. -
Page 22: Patch Panel Selector Switch Fit With Tm-1000 Cable-1
Switch Postion TM-1000 Trunk Lower Input Rx1|Rx2 Trunk Label On patch Panel Table 9. Patch panel selector switch fit with TM-1000 Cable-1, trunks 1-16 and 65-80 3.5. Patch panel selector switch fit with TM-1000 cable- Switch 9 Switch 10 Switch 11... -
Page 23: Patch Panel Selector Switch Fit With Tm-1000 Cable-3
Switch Postion TM-1000 Trunk Lower Input Rx1|Rx2 Trunk Label On patch Panel Table 11. Patch panel selector switch fit with TM-1000 Cable-3, trunks 33-48 and 97-112 3.7. Patch panel selector switch fit with TM-1000 cable-4 Switch 9 Switch 10 Switch 11... -
Page 24: Rj45 (Rj48C) Connector
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 3.8. RJ45 (RJ48C) Connector Connector front view Pin number Description Rx Ring 1 Rx Tip 1 Not connected Rx Ring 2 Rx Tip 2 Not connected Not connected Not connected Table 13 RJ-45 (RJ-48C) E1/T1/J1 Page 24 of 32 Copyright ©... -
Page 25: Tm-1000 Hardware Installation
Connect your trunk input with the RJ-45 connectors in the patch panel (Reference Section 3 of this document). Connect the null serial cable between the TM-1000 and your server (Reference Section 0 of this document for DB-9 connector pin out). -
Page 26: Configure The Tm-1000
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 5. Configure the TM-1000 You will need two free IP addresses on two subnets from your network to configure the TM-1000. (One IP address per subnet.) 5.1. Configure the TM-1000 with the serial port For serial connection, configure the terminal console application, like Hyper terminal at 9600 BPS, 8 bits, no parity, 1 stop bit, no flow control. -
Page 27: Set The Com Port
9000-00015-1A CONFIDENTIAL TM-1000 Installation Guide for Toolpack 5.1.2. Set the com port Figure 24 Hyper Terminal configuration step #2 5.1.3. Set Bits rate Flow control Figure 25 Hyper Terminal configuration step #3 Copyright © 2003-2016 by TelcoBridges Page 27 of 32... -
Page 28: The Tm-1000 Should Be Connected
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 5.1.4. The TM-1000 should be connected Figure 26 Serial connection should be enabled Then press the Enter key to see the following command prompt: TB640> Page 28 of 32 Copyright © 2003-2016 by TelcoBridges... -
Page 29: Configure Ip Addresses
At the TB640> command prompt type “set_net” to modify the network configuration of the TM-1000. It includes the name of the TM-1000, if the DHCP is enabled or disabled, the IP address, the netmask and the gateway address of both Ethernet ports. -
Page 30: Print_Net Command
TM-1000 Installation Guide for Toolpack CONFIDENTIAL 9000-00015-1A 5.2.2. print_net command To validate the “set_net”command, type “print_net” at the shell prompt of the TM-1000. The following information should be displayed: Figure 28 print_net command Page 30 of 32 Copyright © 2003-2016 by TelcoBridges... -
Page 31: Software Installation
7. Upgrading the TM-1000 Firmware and license The TM-1000 starts from the local file system located on the flash memory. The flash memory comes with a version of the firmware available at production time. The Toolpack framework will update the firmware of the TM-1000 automatically to the installed Toolpack version. -
Page 32: Toolpack Api
• The Toolpack HTML API reference can be found in the tb-doc-dev.zip from the packages download. For example, to download the API for 2.9.40, the path would be (user:telcobridges; pass: tbsupport): http://download.telcobridges.com/release2.9.40_dev/tb-doc-dev.zip • Unzip the file, and open tb/doc/toolpack/html/index.html •...
