HSY F107E User Manual

Fi n gerpri n t Access Control System
User Manual
Due to continuous update of our products
II.Inputting Fingerprint
Suggested finger: index finger, middle finger or
ring finger instead of thumb or little finger
1)Correct method
2)Wrong methods
Incomplete touch
Turn sideway
Please input fingerprint correctly for verification,
and improper operation might
result in poor performance of this device
Use the finger to evenly press
the center of fingerprint are
Off cente
Low position
I.Product Overview and Installation Instruction
Applicable Models
Status light
Fi n gerpri n t-readi n g are
Keypad
Card-reading are
Doorbell
Operating Environment:
Rese
Room temperature: -20°C-+50°C
USB
Relative humidity: 95%
Fixing hole
Operating Voltage & Current:
Input DC: +12V
Standby current:≤60mA
Operating current:≤120m
Mounting screws
Set screw
Ports & Wiring Diagram
Connect this device and breaker via NO, COM and NC
output to separate from internal circuit of this device.
Once relay gets closed, electric lock is released.
Contact output current:3A;
connection diagram:
please refer to right diagram.
High level output in case of alar
Alarm Port
Connection Diagram
Wiring Diagram
Power
Optional
Alarm
Note: negative pole
Lock
of normally-closed
to NC port;
normally-open
end to NO port
Door open button
Access controller
Optional
Functions
S.N.
Dark-background fingerprint reader
Built-in card reader
User verification with fingerprint or card
Numeric keys
Tamper alarm
Reading head for data output
86mm box-type panel for installation
Relay Output Connection Diagra
Black
Red
Gray
Blue
Red
Orange
Purple
Black
Yellow
Black
Pink
Light green
White
Green
