Neptronic HRC20 Specification And Installation Instructions

Model

HRC20

Description

The HRC20 is a wall mounted humidistat capable of monitoring
and controlling relative humidity for applications using a room
distribution system. Its primary function is to act as a room
sensor for On/Off humidifiers.

Features


On-board setpoint adjustment (10 to 60%RH)

Built-in humidity sensor

Plastic cover for wall mount installation

24Vac or 24Vdc

1 dry contact output (normally open)

Technical Specifications

Specifications
Power supply
Power consumption
Electrical connection
Humidity sensor precision
Setpoint range
Operating temperature
Storage temperature
Relative humidity
Enclosure protection
Weight
Dimensions
A = 2.85" (73mm)
B = 4.85" (123mm)
C = 1.00" (24mm)
D = 2.36" (60mm)
E = 3.27" (83mm)
HRC20-180522-ESA
24 Vac or Vdc ±10%
1 VA
2
0.8 mm [18 AWG] minimum
±3% at 40 %RH and 23ºC [73ºF]
10 to 60 %RH
32ºF to 104ºF [0ºC to 40ºC]
14ºF to 122ºF [-10ºC to +50ºC]
0 to 95 %RH
IP 30 (EN 60529)
0.13 lb [60 g]
B E
A
www.neptronic.com
Specification and Installation Instructions
HRC20
HRC20
D
C
Room Humidistat
Page | 1
