Matrix G3S75 Assembly Manuallines

Step 1
G35 x24
G34 x16
G33 x16
Arc-flat Item Description
Allen Head
Washer
G33 Flat Washer (M10)
Cap Screw
G34 Lock Washer (M10)
G35 Screw (M10x25L)
Lock
G37 Arc-flat Washer (M10)
Washer
Flat Washer
Step 2
Item Description
Input Detail
B28 Screw (M8x30L)
L10 Flat Washer (M8)
L11 Lock Washer (M8)
D21 Bushing
Set Screw (M5x25L)
D41 Screw (M5x10L)
H30 Flat Washer (M12)
D41
H24 Lock Washer (M12)
H12 Screw (M12x25L)
D26 Cam Stopper
D41 x2
E10 Nylon Nut (M8)
CABLE - D17 D21 x2 D47 Screw
D18 Spacer
H30 x2
H24 x2
D26 x1
E10 x8
H12 x2 D47 x1
D18 x1
D44 x2
B28 x8
L11 x8
L10 x8
G3S75 HIP ABDUCTOR
G3S75- HIP ABDUCTOR
UNPACKING G3S75 HIP ABDUCTOR
Thank you for purchasing a MATRIX Fitness product. Carefully unpack the unit from this box
Sketch Qty and dispose of the packing materials in accordance with your local laws.
16
16
24
CAUTION
8
The weight of the G3S75 Hip Abductor is 703 lbs. (319 kg) not including the weight stack. To
avoid injury to yourself and prevent damage to the frame components, be sure to have proper
assistance removing the frame pieces from this box.
TOOLS NEEDED
Sketch Qty
DESCRIPTION
8
8
3MM L-Shaped Allen Wrench
8
2 4MM L-Shaped Allen Wrench
2
5MM L-Shaped Allen Wrench
2
2
6MM L-Shaped Allen Wrench
2
2
8MM L-Shaped Allen Wrench
1
8
10MM L-Shaped Allen Wrench
1
1
Phillips Screwdriver
8MM Open-End Wrench
17MM Open-End Wrench
Guide Rod Lubrication
Hardware Bag
If any items are missing please contact your country's local Matrix dealer for assistance.
Step 3
Item Description
Upholstry Detail
Screw (M10x25L)
D42
D42 x13
SKETCH QUANTITY
1
1
1
1
1
1
1
1
1
1
Step 4
Sketch Qty
Weight Stack Detail
13
K13 x4
L14 x4
F25 x4
K05 x1
F24 x4
INCREMENTAL
WEIGHT B28 x2
L09 x2
K18 x2 10
L11 x2
25
40
55
70
85
100
115
130
145
160
175
190
205
220
235
250
265
280
295
K07 x2
Step 5
Belt & Cable Routing Detail
Belt
Screw
Flat Washer
Belt Fixer
Lock Washer
F22
F25
F24
F06
Step 6
Accessory Detail
B51 x6
B43 x6
Upper Cover x2
Q06 x6
Weight Shield
Item Description Sketch Qty
B28 Allen Head Cap Screw (M8 X 30L) 2
F24 Flat Washer (M5) 4
K05 Knurled Belt Securing Insert 1
K07 Rubber Stack Cushions 2
K13 E-Clipper (E-15) 4
Flat Washer (M8) 2
K18
L09 Screw, Oval-Hex Socket (M8 X 20L) 2
Lock Washer (M8)
L11 2
F25 Lock Washer (M5) 4
Screw, Oval-Hex Socket (M5 X 16L)
L14 4
Guide Sleeve
Knurled Belt
Securing Insert
Guide Rod
Screw
Top Weight
10
Selector Pin
Qty
Item Description Sketch
F06 Belt Fixer 2
4
F22 Allen Head Cap Screw
4
F25 Lock Washer
4
F24 Flat Washer
G31 Screw, Oval-Hex Socket 4
BELT
G31
B28 x2
B47 x2
Towel / Water
Description
Bottle Holder
Panel
Item Description Sketch Qty
B28
Screw (M8 X 30L) 2
B43 Screw (M4 X 12L)
6
B47 Screw (M8 X 18L)
2
Q05
Rubber Shield Spacer 6
Q06 Rubber Tip Weight Shield Bolt 6
B51 Internal Tooth Lock Washer
6
