Scout ADS-B Quick Start Manual

STEP
Slide one suction
cup into the gimbal
mount at the top of
Scout, and slide the
other into the
separate cable clip.
STEP
Insert the
Micro-USB cable
into Scout, then
secure Scout to a
surface using the
first suction cup.
ADS-B Receiver
Quick Start Guide
1
2
2
1
2 3
STEP
3
Slide the cable clip
with suction cup
onto the cable and
1 press it onto the
same surface to
secure Scout from
both ends.
STEP
4
Plug the other end
of the Micro-USB
cable into a power
source. One light
indicates power;
two lights indicate
reception from an
ADS-B tower.
4
3
4
5 6
