Accel FX Power Source 10M User Manual

INPUT:

Detachable 18V AC power adaptor
Country
North America
OUTPUTs:

All DC Outputs are regulated

Over current protection on each output
Output DC Voltage
1-7 9V
8 9V
9 12V
10 18V
Limited 2 Year Warranty
This warranty covers any defects or malfunctions in your new Accel FX Power Source 10M
Power Supply. This a 2 year warranty for the original registered purchaser. Accel will fix or
replace any defective units with the first 2 years from the purchase date. Fixing or replacing
the unit will be at Accels discretion. Any problem that is caused by abuse, misuse, or an act of
God (such as a flood) are not covered. In order to be eligible for service under this warranty
you must return the warranty registration card attached below within 30 days of purchasing
the aid.
If something goes wrong with your Accel Power Source 6 Power Supply, email us at
support@accelaudio.com
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Input AC Volt
120V/60Hz
Current
100mA
500mA
100mA
100mA
Warranty
4
USER'S MANUAL
Table of Contents
What's Included..............................1
Introduction & General Information.....1
Warnings & Cautions..................... .2
Component Description and
Dimensional Drawing...................... .3
Power Supply Mounting Instructions....3
Specifications.................................4
Warranty........................................4
Introduction:
Your Accel "FX Power Source 10M" Ten Output Power Supply is designed with a high efficiency
transformer. Each output is fully regulated and filtered with over voltage protection.
Equipped with an on/off switch and our easy mount, mounting wings, adds an extra level of
convenience not found on similar power supplies.
The FX Power Source 10M , powers 9V, 12V & 18V effects pedals.
Outputs 1-7: 9V@ 100 mA powers the majority of the pedals on the market.
Output 8: 9V @ 500mA powers the 9V pedals and switchers that require more mA's
Output 9: 12V @ 100mA powers most of your favorite 12V effects.
Output 10: 18V@ 100Ma powers most of your favorite 18V effects.
Read all warnings, cautions and operating instructions before using this product.
What's Included
(1) Accel FX Power Source 10M Power Supply
(1) User Manual
(1) 18V adaptor
(10) Negative Center Output Cables
(2) Reverse Polarity Cables
1
