- Page 1 HDMI Over IP-PRO DSX HDMI Over IP-PRO DSX RS-232 controls -Samsung TV with EXLink Revision: 1.2 Date : 8/29/18 HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 2 The Octava PRO DSX HDMI Over IP system enables routing of RS-232 control signals for enhanced system integration. The ExLink port allows serial control of the Samsung TV. For example, turn on/off , changed channels and etc. The ExLink cable has a 3.5mm jack (like a audio headphone cable) on one side and on the other side is an RS-232 interface.
- Page 3 Telnet the RS-232 to the PRO DSX-RX connected to TV1 TV 1 TV 2 EXLINK EXLINK HDMI HDMI CATx PRO DSX –RX Receiver CATx CATx Controller RS-232 HDMI Source 1 PRO DSX –TX Transmitter HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 4 1. Configure the PRO DSX-RX Serial IP to Type 2 GUEST Mode Use browser to access the PRO DSX which you wish to send RS-232 commands to Enable Serial Over IP Select Type 2 Set the Baud rate settings per requirements. HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 5 2. Apply and Reboot You will need to Reboot to save the TYPE 2 Guest Mode Settings Reboot HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 6 2. Send the HEX command to the SAMSUNG TV that you wish. HEX Command Example Power ON \x08\x22\x00\x00\x00\x02\xD4 Power OFF \x08\x22\x00\x00\x00\x01\xD5 Volume UP \x08\x22\x01\x00\x01\x00\xD4 Volume Down \x08\x22\x01\x00\x02\x00\xD3 HDMI IN 1 \x08\x22\x0A\x00\x05\x00\xC7 HDMI IN 2 \x08\x22\x0A\x00\x05\x01\xC6 HDMI IN 3 \x08\x22\x0A\x00\x05\x02\xC5 HDMI IN 4 \x08\x22\x0A\x00\x05\x03\xC4 HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 7 The ExLink cable has a 3.5mm jack (stereo )on one side and on the other side is an Phoenix Style ( green)RS-232 interface. You may use any 3.5 mm stereo cable and make your own interface cable as shown below. PRO DSX-RX RS-232 EX LINK HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
- Page 8 Contact Information Octava Inc.-7078 Peachtree Ind. Blvd Suite 300 Norcross, Ga. 30071 Tel 770.825.0388 www.octavainc.com Email: info@octavainc.com HDMI Over IP-PRO DSX RS-232 Controls Samsung ExLink...
