Summary of Contents for Shademaker Orion 2.5
- Page 2 Those filing warranty claims will be responsible for all shipping, handling and freight charges on all claims to Shademaker in Baldwin Park, CA. All warranty claims must be submitted with the original proof of purchase, date of purchase, name of dealer and the description of the damage.
- Page 3 I M P O R T A N T : Please read this entire manual before installing or operating your Orion umbrella. O R I O N W I N D R E S I S T A N C E G U I D E L I N E S : Moderate to Moderately Strong Winds When installed properly, the Orion is engineered to handle moderate to moderately strong wind conditions in the open canopy position.
- Page 4 The Orion is an excellent choice for windier locations. The Orion sidepost combines the sizing of the Sirius with the styling of the Galaxy. Two Shapes Five Sizes Orion 2.5 8’2” Square Orion 3.0 9’7”...
- Page 5 A B O U T T H E O R I O N This high quality shade solution combines functionality and design in an elegant way and will provide you with years of enjoyment and satisfaction. 1. MARINE GRADE ANODIZED ALUMINUM: Proprietary extrusions of high tensile alloy ensure long life in exposed conditions.
- Page 6 C O M P O N E N T S , F I T T I N G & H A R D W A R E 1. INTERNAL STEM: The Orion mast slides directly over the internal stem as a sleeve. The plate of the internal stem is 9”...
-
Page 7: Installation Instructions
INSTALLATION INSTRUCTIONS To ensure proper installation, please carefully read these instructions before installing your base plate or in-ground fitting. PROPER ALIGNMENT OF THE ORION If the exact position of the Orion canopy (when in the open position) is important to you, it is imperative that the installation fitting (base plate or in-ground fitting) is properly aligned. - Page 8 I M P O R T A N T : Insert the Spacer Buttons Immediately! It is imperative that the eight (8) spacer buttons (white plastic cups/screws) are inserted after the canopy is opened for the first time. Spacer buttons stop the arms from closing completely and make it much easier to open the canopy singe-handedly.
- Page 9 O P E R A T I N G I N S T R U C T I O N S By now, you have installed your base plate(s) or in-ground fitting, bolted your Internal stem to the base plate or in-ground fitting, and have followed the early instructions to slide the mast over the newly mounted internal stem.
- Page 10 T O S E T T H E C H I L D S A F E T Y L O C K B U T T O N In any of the positions, the child safety lock button can be set by pushing the button in and turning it 90 degrees clockwise.
- Page 11 T O P R O P E R L Y F O L D T H E O R I O N C A N O P Y The 100% solution dyed acrylic canopy will last longer if you fold it as it was packed and shipped.
- Page 12 O T H E R S H A D E M A K E R S T Y L E S A V A I L A B L E Side Posts Galaxy Sirius Center Posts Top Mount Astral Corona Nova 13401 Brooks Drive Baldwin Park, CA 91706 p 626.338.8810 f 626.338.8816 info@shademakerusa.com shademakerusa.com © 2010 Shademaker. All rights reserved. SMOM-ORION-810...
