Model 808 Laser Pointer Manual
① Install star caps or attachment here.
② Screw in/out to adjust the laser beam.
③ On/Off button.
④ This laser uses 2 x 16340 Li-ion 3.7V batteries.
Technical Specs
Name
Size
Laser Class
Laser Type
Wavelength
Output Power
Beam Divergence
Beam Diameter
Laser Body
Laser Finish
Modes
Power Supply
Working Voltage
Weight
facebook @ laserpointerstore
2*16340 or 1*18650 Lithium-Ion Rechargeable Battery (package not include)
www.laserpointerstore.com
Model 808 Laser Pointer
18*2.5 cm
Class 3 - 4
Direct Diode
450nm blue
1000mw
3.6mRad
4mm At Aperture
<20mm at 10 meters
Aircraft-Grade Aluminum
Black / Gold
On/Off
3.7V
0.08kg
Made in China
Advertisement
Related Manuals for MLLSE 808
Summary of Contents for MLLSE 808
- Page 1 Model 808 Laser Pointer Manual ① Install star caps or attachment here. ② Screw in/out to adjust the laser beam. ③ On/Off button. ④ This laser uses 2 x 16340 Li-ion 3.7V batteries. Technical Specs Name Model 808 Laser Pointer Size 18*2.5 cm...
- Page 2 Expected Life Time >6000 hours Warranty 6 month Important things: 1. Must use safety goggles. Get one from us if you don’t have one. 2. Don’t light up over 2 minutes each time, totally cool down before you use it again, if or, it may be damaged by overheated.
