Summary of Contents for MultiMax MA-2040
- Page 1 Digital Input & Output Configuration Multimax DI/DO configuration Page 1 / 10 and Testing Documents...
- Page 2 FORUM: www.maxon.com.au/forum ADDRESS: Maxon Australia Pty Ltd 36a Gibson Avenue, Padstow Sydney, NSW, Australia 2211 POSTAL ADDRESS: Maxon Australia Pty Ltd Po Box 1, Revesby North, Sydney, NSW Australia 2212 Multimax DI/DO configuration Page 2 / 10 and Testing Documents...
- Page 3 Only use original accessories or accessories that are authorized by the manufacturer. Using unauthorized access ories may affect your modem’s performance, damage your modem and violate related national regulations. Multimax DI/DO configuration Page 3 / 10 and Testing Documents...
- Page 4 Revision History Updates between document versions are cumulative. Therefore, the latest document version contains all updates made to previous versions. Release Date Firmware Version Details 2013-9-1 01.00 First Release Multimax DI/DO configuration Page 4 / 10 and Testing Documents...
-
Page 5: Table Of Contents
Benefits ............................... 4 Chapter 2. Configuration ............................6 Configure Phone Book ........................6 Configure DI/DO --> DI........................7 Configure DI/DO --> DO ........................8 Chapter 3. Start Testing ............................9 Multimax DI/DO configuration Page 5 / 10 and Testing Documents... -
Page 6: Chapter 1. Introduction
Multimax provides two digital inputs (DI) and two digital outputs (DO), which meet the application requirement of supervisory control and monitoring system. For example, when one temperature sensor ’s sampling temperature is out of normal level, Multimax connecting to sensor will send out alarm SMS. -
Page 7: Connection Diagram
“12VDC”to power input (which standard powerinput is 12VDC), and then use a serial electric line connect “GND” to “V-” (GND of 12VDC power). Note: please check the connector interface of Multimax you can find out “V-” easily at one of the pin of power input connector. -
Page 8: Chapter 2. Configuration
“Phone Book”. 1. Open Multimax’s Web GUI, go to “Configuration” --> “Phone Book” --> click “Add” to add phone number in tab “Phone No.” and enter specific description at tab “Description”. For example, when you enter Saroj’s Phone No. - Page 9 Multimax DI/DO configuration Page 9 / 10 and Testing Documents...
- Page 10 Off” in “Triggering Alarm” and “Recovering Alarm”, select the Phone Group who you want to send out SMS Alarm to. Repeat this for DI_2 configuration--> click “Apply” at the right button of the page. Multimax DI/DO configuration Page 10 / 10 and Testing Documents...
- Page 11 10 sec. If you leave 0, the output will be on until you turn off the Output. --> Click “Apply” at the right button of the page. Multimax DI/DO configuration Page 11 / 10 and Testing Documents...
- Page 12 Digital Output If SMS Control is configured as DO Alarm source, when send specific SMS to Multimax, DO will connect to GND (which has connected to V-), and then LED will be lit up. If Call Control is configured as DO Alarm source, when specific user make a call to Multimax, DO will connect to GND (which has connected to V-), and then LED will be lit up.
- Page 13 Close slide switch LED, Saroj’s mobile phone will receive a SMS “Digital Input 1 on”, Multimax DI/DO configuration Page 13 / 10 and Testing Documents...
